Digital Watchdog - DW-BJPR2U60T-LX - Blackjack P-Rack 2U 8-Bay Chassis with RAID-50 TB

Linux Ubuntu 16.04 OS, Raid 5 50TB usable RAID storage

Part number:
DW-BJPR2U60T-LX
Price:

Blackjack® P-Rack™ servers can record and manage single- and multi-sensor IP cameras of any resolution, with an equivalent capacity of up to 128 2.1MP cameras at 30fps and a maximum of 600Mbps throughput. Standard features include Intel® i7®, Windows® 10 Pro or Linux® Ubuntu® OS and 2x NIC cards. Blackjack® P-Rack™ servers can be configured with 30-50TB recording storage and come with our 5 year limited warranty.

  • Supports All ONVIF conformant IP cameras
  • Storage options 40-60TB internal storage
  • Data redundancy
  • Record and manage single- and multi-sensor IP cameras of any resolution up to 128 2.1MP cameras at 30fps and a maximum of 600Mbps throughput
  • True HD and DVI local monitoring outputs ports
  • Dual network ports
  • Windows® 10 Pro or Linux® Ubuntu® 16.04 OS on separate SSD
  • USB interface
  • Hosting DW Spectrum® IPVMS for setup, configuration, monitoring and recording
  • One-time recording license charge, fully transferable between cameras and encoders
  • One (1) DW Spectrum® IPVMS 4-channel licenses included (DW-SPECTRUMLSC004)
  • No annual maintenance fees
  • Simple enterprise scalability
  • Auto device discovery
  • Dual stream recording
  • Rail kit included
  • USB mouse and keyboard included
  • Designed, assembled and tested in the U.S.A.
  • NDAA/TAA compliant
  • 5 years limited warranty
Maximum IP cameras
128 (2.1MP/1080p @30fps, with medium recording quality)
Included IP licenses
4
Form factor
Rack mount
Operating system
Windows® 10 Pro
DW-BJPR2UXXT
Linux Ubuntu® 16.04
DW-BJPR2UXXT-LX
OS on SSD
150GB SSD


CPU
Intel®i7® processor
Memory
16GB
Ethernet port
2x gigabit ethernet ports (RJ45)
Option: DW-R4NIC - upgrade quad 1GB NIC card *
System
Max video storage rate (Mbps)
600 Mbps
Storage
Maximum hard drives
6 x SATA HDD
Maximum storage
50TB RAID 5
Video-out
Outputs
True HD output or VGA or DVI
Video card
GeForce 210 512MB
Option: DW-RV4H - 4 head HD video card*
Resolution
HD 1080p
Pre-loaded VMS software
DW Spectrum® IPVMS
Remote clients
Cross platform - Windows®, Linux Ubuntu® and Mac®
Mobile apps
iOS® and Andriod®
Keyboard & mouse
Included
Rail kit
Included
Power supply
400W**
Operating temperature and humidity
41°F~104°F (5°C~40°C)
Operating humidity
20~90% RH
Dimension (WxDxH)
17.32" x 26" x 19" (439.9 x 660.4 x 482.6 mm)
Warranty
5 year limited
