Digital Watchdog - DW-BJRR2P192T - 32GB dual Intel Xeon Silver processor 2U rackmount server
Part number:
DW-BJRR2P192T
Price:

This dual processor Blackjack® Rack™ server is the ultimate solution for recording multiple IP cameras of any resolution at up to 600Mbps throughput. The server is NDAA/TAA compliant, UL listed and includes Windows 10®, Windows Server® 2019 or Linux® Ubuntu® OS on a separate 240GB NVMe SSD. The 2U rack-mountable hardware features dual Intel® Xeon® processors, 32GB memory, dual network cards, dual power supply, mini DisplayPort outputs and removable hot-swappable drives. The Blackjack Rack server comes preloaded with DW Spectrum® IPVMS and eight recording licenses, up to 192TB raw internal storage with RAID5 and is ONVIF conformant The server comes complete with a 5-year, on-site, Next Business Day**, Keep Your Hard Drive warranty to ensure peace of mind.



Features :

  • Supports ONVIF conformant IP cameras
  • Storage options 64-192TB raw internal storage with RAID5
  • Hot-Swappable HDDs
  • Redundant power supply
  • Dedicated GPU for client application for easy configuration
  • Intel® Xeon® processor
  • Dual network ports
  • Windows 10®, Ubuntu® Linux®, Windows Server® 2019 OS on NVMe SSD, RAID1
  • Hosting DW Spectrum® for setup, configuration and recording
  • One-time recording license charge, fully transferable between cameras and encoders
  • Two (2) 4-channel licenses included for a total of 8 recording channels (DW-SPECTRUMLSC004)
  • No annual maintenance fees
  • Simple enterprise scalability and auto device discovery
  • Dual-stream recording
  • Rail kit included
  • USB mouse and keyboard included
  • Designed, assembled and tested in the U.S.A.
  • UL listed
  • NDAA/TAA compliant
  • 5 year warranty, next business day on-site hardware service*, keep your hard drive - *after remote diagnosis
Included IP licenses8
Form factor2U Rackmount
Operating systemWindows® 10

DW-BJRR2PxxT



Linux Ubuntu® 18.04 LTSDW-BJRR2PxxTLX
Windows Server® 2019DW-BJRR2PxxTS
OS on NVMe SSD2 x 240GB NVMe SSD (RAID1)
CPUDual Intel® Xeon® Silver processor
Memory32GB (4x 8GB)
Ethernet port2 x 1Gigabit Ethernet (RJ45)
Option: DW-BJRR10GBN - Dell Broadcom 57412 Low Profile Dual Port 10Gb SFP+ NIC***
SystemMaximum video storage rate (Mbps)600 Mbps
Storage

Maximum HDD



12 x 3.5" SATA HDD



 Maximum storageMax raw 192TB, RAID5
Video-outOutputs3 x mini DisplayPort (1 x mini-DP to true HD adapter included)
Video cardNvidia Quadro P400
Pre-loaded VMS softwareDW Spectrum® IPVMS
Remote clientsCross-platform - Windows®, Linux Ubuntu® and Mac®
Mobile appsiOS® and Andriod®
DW Site Viewer
DW Spectrum App
Keyboard and mouseIncluded
Rail kitIncluded
Power supplyDual 750W Redundant*
Operating temperature (ambient room temperature)41°F~104°F (5°C~40°C)
Operating humidity5~85% RH
Dimension (WxDxH)19” x 28.25” x 3.41” (482.6 x 717.55 x 86.61mm)
Certification FCC and CE
Warranty5 year warranty with next business day on-site hardware repair
