Digital Watchdog - DW-BJT71140T - Blackjack tower, Windows OS on SSD, 600Mbps throughput, Intel i7, 16GB RAM, hot-swappable, 140TB storage, UL
Part number:
DW-BJT71140T
Price:

Blackjack Tower servers are reliable and high-performance solutions for recording multiple IP cameras of any resolution at up to 600Mbps throughput. The servers are UL-listed and NDAA/ TAA compliant and come pre-loaded with DW Spectrum IPVMS and four complimentary recording licenses, provide up to 140TB internal storage, hot-swappable drives, are ONVIF conformant and come with a 5 year limited warranty



Features:

  • Supports all ONVIF conformant IP cameras
  • Up to 140TB internal storage
  • Hot-swappable HDDs
  • Record and manage single- and multi-sensor IP cameras of any resolution up to 600Mbps throughput
  • OS on separate SSD
  • Hosting DW Spectrum for setup, configuration and recording
  • One-time recording license charge, fully transferable between cameras and encoders
  • One (1) 4-channel license included (DW-SPECTRUMLSC004).
  • No annual maintenance fees
  • Simple enterprise scalability
  • Auto device discovery
  • Dual-stream recording
  • USB mouse and keyboard included
  • Designed, assembled and tested in the U.S.A.
  • UL Listed
  • NDAA/TAA compliant
  • 5 year limited warranty
VIDEO
CPUIntel i7 processor
Display ModesUnlimited, Customizable, Sequence
Display SpeedUp to 30fps per channel
Local Video Output ResolutionHD 1080p
Local Video OutputsFor initial configuration and server management, 1 DisplayPort, DVI, True HD, 1 display output at a time
Memory16GB
Video CardOn-board Intel Graphics
Video CompressionH.264, H.265
Video Operating SystemLinux Ubuntu Desktop 20.04.5 LTS OS (DW-BJT7120TLX, DW-BJT7140TLX, DW-BJT7160TLX, DW-BJT7180TLX, DW-BJT71100TLX, DW-BJT71120TLX), Windows 10 IoT Enterprise LTSC (DW-BJT7120T, DW-BJT7140T, DW-BJT7160T, DW-BJT7180T, DW-BJT71100T, DW-BJT71120T, DW-BJT71140T)
OS on SSD240GB SSD
Max throughput (Mbps)600Mbps
STORAGE
Raw internal storage optionsImage removed.Image removed.Image removed.Image removed.Image removed.Image removed.Image removed.
RAID OptionsNo RAID
Max HDD Bay7 x SATA HDD
Maximum Storage100TB (DW-BJT71100T, DW-BJT71100TLX), 80TB (DW-BJT7180T, DW-BJT7180TLX), 20TB (DW-BJT7120T, DW-BJT7120TLX), 40TB (DW-BJT7140T, DW-BJT7140TLX), 60TB (DW-BJT7160T, DW-BJT7160TLX), 120TB (DW-BJT71120T, DW-BJT71120TLX), 140TB (DW-BJT71140T, DW-BJT71140TLX)
PERFORMANCE
Playback FunctionsCalendar, Event search, Smart motion search, Thumbnail search, Timeline
PTZ controlONVIF
Recording ModesContinuous, Motion + low res always, Motion + Object, Motion + Object + Low res, Motion detection, Object + Low res, Object only
System OperationGraphical user interface (GUI), Remote via DW Spectrum IPVMS, USB mouse (included)
NETWORK
BackupNetwork backup via DW Spectrum IPVMS
Ethernet Ports2x 1G Ethernet (RJ45)
Pre-loaded VMS softwareDW Spectrum IPVMS
Network Remote SoftwareCross-platform - Windows, Linux Ubuntu and Mac, DW Mobile Plus, DW Spectrum Mobile App
ELECTRICAL
Power Consumption500W, A UPS is recommended
GENERAL
AccessoriesKeyboard, Mouse
Included IP licenses4
Operating Temperature and Humidity20 ~ 90% RH, 41 ~ 104 °F (5~40 °C)
Recorder Dimensions (H X W X D)8.6” x 19.12” x 16.83” (218.6 x 485.8 x 427.5 mm)
Recording Licenses (Optional. Sold Separately)Custom-ordered licenses are available by request.
DW-SPCP04LSC004 - Four (4) DW Spectrum Analog Encoder IPVMS Licenses
DW-SPCP16LSC016 - Sixteen (16) DW Spectrum Analog Encoder IPVMS Licenses
DW-SPECTRUMLSC001 - Single DW Spectrum IPVMS Recording License
DW-SPECTRUMLSC004 - Four (4) DW Spectrum IPVMS Recording Licenses
DW-SPECTRUMLSC010 - Ten (10) DW Spectrum IPVMS Recording Licenses
DW-SPECTRUMLSC020 - Twenty (20) DW Spectrum IPVMS Recording Licenses
DW-SPECTRUMLSC050 - Fifty (50) DW Spectrum IPVMS Recording Licenses
DW-SPECTRUMLSC100 - One hundred (100) DW Spectrum IPVMS Recording Licenses
DW-SPIOLSC001 - Single DW Spectrum I/O Module IPVMS License
DW-SPVWALL1X2 - Single DW Spectrum Video Wall IPVMS License
Lifetime upgrades are included with no annual renewal fees.
USB interfaceYes
Weight (barebone, HDD not included)19.7 lbs (8.93 kg)
CertificationImage removed.Image removed.Image removed.Image removed.Image removed.Image removed.
Form FactorFull-size Tower
