Digital Watchdog - DW-BJTR71560TS - Blackjack Tower Servers with Intel Core i7 Processor with RAID5, Windows Server OS, 60TB
Part number:
DW-BJTR71560TS
Price:

Blackjack® Tower™ servers are reliable and high-performance solutions for viewing, monitoring and recording multiple IP cameras of any resolution at up to 600Mbps throughput. The servers are NDAA/TAA compliant and include Windows 10®, Windows Server® or Linux® Ubuntu® OS on a separate SSD. Hardware features include an Intel® i7 processor, dual network cards and local true HD, DVI and DisplayPort output up to 4K resolution. The servers come pre-loaded with DW Spectrum® IPVMS and four complimentary recording licenses, provide up to 112B internal storage with RAID5 and RAID6 options, hot-swappable drives, are ONVIF conformant and come with a 5-year limited warranty.

All Blackjack® Tower servers come with one (1) DW-SPECTRUMLS004 4-channel license included.



Features:

  • Supports all ONVIF conformant IP cameras
  • Up to 112TB internal storage
  • OS on SSD
  • RAID5, RAID6 options
  • Record and manage single- and multi-sensor IP cameras of any resolution up to 600Mbps throughput
  • 1 x True HD, 1 x DVI, 1 x VGA, 1 display output at a time, for system configuration
  • Dual network ports
  • Windows 10®, Ubuntu® Linux® and Windows® Server® OS options
  • USB interface
  • Hosting DW Spectrum® for setup, configuration, monitoring and recording
  • One-time recording license charge, fully transferable between cameras and encoders
  • One (1) 4-channel licenses included (DW-SPECTRUMLSC004)
  • No annual maintenance fees
  • Simple enterprise scalability
  • Auto device discovery
  • Dual-stream recording
  • USB mouse and keyboard included
  • Designed, assembled and tested in the U.S.A.
  • UL Listed
  • NDAA/TAA compliant
  • 5 year limited warranty

Included IP licenses

4

Form factor

Full-size tower

Operating system

Windows® 10 DW-BJTR715xxT/
DW-BJTR716xxT
Linux Ubuntu® DW-BJTR715xxTLX/
DW-BJTR716xxTLX
Windows Server® DW-BJTR715xxTS/
DW-BJTR716xxTS
OS on SSD 240GB SSD

CPU

9th Gen Intel® Core™ i7 processor

Memory

16GB

Ethernet port

2 x 1Gigabit Ethernet (RJ45)

System

Max video storage rate (Mbps)

RAID5: 600Mbps
RAID6: 420Mbps

Storage

Maximum storage drives 7 x 3.5 SATA HDD

Maximum storage

Maximum raw 112TB
RAID options RAID5, RAID6
Video-out

Outputs

1x true HD, 1x DVI, 1x DisplayPort, for system configuration.
Maximum 1 display output at a time.

Video card

Onboard Intel graphics

Preloaded VMS software

DW Spectrum® IPVMS

Remote clients

Cross-platform - Windows®, Linux Ubuntu® and Mac®

Mobile apps

iOS® and Andriod®
DW Site Viewer
DW Spectrum App

Keyboard and mouse

Included

Power supply

500W**

Operating temperature (ambient room temperature)

41°F~104°F (5°C~40°C)

Operating humidity

20~90% RH

Dimension (WxDxH)

8.6” x 19.12” x 16.83” (218.6 x 485.8 x 427.5 mm)
Other certifications UL listed, ONVIF, NDAA/TAA, CE, FCC

Warranty

5 year limited
Name
Description
Size
Downloads
File
Datasheet
1mb
File
Quick Setup Guide
0.6mb
File
Blackjack Brochure
1mb
File
AE Specifications
0.1mb
