Digital Watchdog - DW-COVA1616T - 16 Channel PoE Cloud-Optimized Video Archiving Network Video Recorder, 16TB
• Record and manage single-sensor IP cameras at real-time 30fps up to 8K, with 192Mbps maximum throughput
• 16GB myDW cloud storage for Clip Share included
• Includes a 12-month subscription to myDW services
• Local power for up to 16 IP cameras via a resident PoE switch makes the installation seamless and efficient.
• Remote user and event management via myDW Cloud Video Services
• Upload events to myDW via Clip Share to address critical events quickly and efficiently.
• Up to 32TB local storage
• Compatible with ONVIF cameras
• Live, playback and video archiving via the web client
• Static and dynamic live camera views
• Event notifications and system health reports via myDW
• IdentiSee enables the search for individuals and vehicles that AI cameras have detected.
• Audio communications from supported IP cameras
• Local alarm sensor input and relay output for access control integration
• NDAA-compliant for federal and government projects
• 19” rack mount ears included
• Full 5-year warranty
| VIDEO | |
| Operating system | Embedded Linux |
| SYSTEM | |
| Channels | 16 channels |
| Number of PoE ports | 16 PoE ports |
| Supported camera resolutions | Up to 8K (16MP) |
| DISPLAY | |
| Video output ports | True HD, VGA |
| Video output resolution | True HD: 3840 x 2160 / 1920 x 1080 / 1280 x 1024 / 1024 x 768 VGA: 1920 x 1080 / 1280 x 1024 / 1024 x 768 |
| Display speed | Real-time 30fps live display per channel. |
| Screen display mode | 1, 4, 9, 16 |
| PORTS | |
| System operations | USB mouse |
| USB | USB 2.0 x 2 |
| LOCAL PERFORMANCE | |
| Recording resolution | Up to 16MP |
| Recording speed | Up to 30fps per channel in any resolution |
| Maximum throughput | 192 Mbps |
| Recording modes | Schedule, continuous, event |
| Decoding Live view and playback | Up to 30fps |
| AUDIO | |
| Network input | 16-channels input from supported IP cameras |
| Local input/output | Disabled |
| Compression | G.711(U/A) |
| ALARM | |
| Input | 8 In |
| Output | 4 Out |
| Triggering | Record, snap, preset, e-mail, etc. |
| STORAGE | |
| HDD interface | 2x SATA HDDs |
| Maximum internal storage | Up to 32TB |
| NETWORK PERFORMANCE | |
| LAN | 10/100/1000Mbps Ethernet (RJ45) |
| Compression | H.265 / H.264 |
| Protocol | TCP / IP, IPv4, IPv6, UDP, DHCP, DNS, DDNS, UPnP, NTP, HTTP, SMTP, 802.1x, RTSP, RTP, RTCP, WebSocket, ONVIF |
| ACCESS | |
| Remote web client features | Live monitoring, remote playback and file backup Playback up to 16 channels, 30fps per channel Timeline, calendar (date and time), event search, Identisee Remote system reboot, FW updates, system management and remote PTZ control. |
| myDW camera health monitoring | Cloud-Base Health Monitoring User management, events and system health notifications, video share and cloud upload Remote system reboot, FW updates and system management |
| Max stream connections | up to 64CH, Playback: up to 16CH |
| Remote time sync | Time synchronization to an NTP server (pool.ntp.org) |
| System recovery after power failure | Auto-reboot and journaling file system |
| Backup | Over the network, video share via myDW cloud-based VMS |
| GENERAL | |
| Operating temperature | 14 ~ 122°F (-10 ~ 50°C) |
| Operating humidity | 10% ~ 90% humidity |
| System Power requirements | DC48V/3.75A |
| Power consumption | Up to 20W ( without HDD and PoE power supply ) |
| PoE | |
| PoE ports | RJ 45 100Mbps x 16 |
| Standards | IEEE802.3AF/AT |
| Maximum power per port | 802.3AT |
| Output power | Up to 150W |
| Dimensions (WxDxH) | 14.96" x 10.55" x 1.77" (380 x 268 x 45mm) |
| Certificate | CE, FCC, NDAA, RoHS |
| Warranty | 5 year warranty |
COVA is DW’s user-friendly recording solution for myDW subscribers. It combines cloud monitoring, health management and clip sharing with on-site storage, offering optimised security. The COVA NVR is managed via the myDW Cloud Video Services. Video can be recorded locally, and live viewing, playback, event notifications and user management are available via the myDW cloud web client and the DW Mobile+ app. The hardware has 16 built-in PoE ports with 25.5 watts of power and supports real-time recording at 30 fps with a resolution of up to 8K (16 MP), as well as offering up to 32 TB of storage. It is protected by DW’s 5-year warranty.
