HD Analog Resolution

Support for all analog signals and HD analog signals up to 5MP.

PathFinder

Easy and secure remote connection with NAT Traversal (STUN/TURN) support without opening ports.

C3 CMS

C3 CMS takes video management to the next level. You are in complete command to control all your video surveillance systems in one intuitive interface. Easy-to-program alerts let you take action in real-time and manage the health of your devices.

Group Recording

Designate a group of cameras to respond to an alert from one camera.

Channel Swap

Swap a camera’s channel assignment without changing the cable connections.

Status Monitoring

A real-time graphical representation of all system connections. Receive connection alerts via email or text.

Designed and commissioned in the U.S.A

All DW recorders, workstations and NAS devices are designed, assembled and inspected in our California facility. Each product undergoes multiple levels of quality control to guarantee the highest quality and performance.

Features

• Universal HD over Coax DVR records HD-Analog and HD-TVI and all analog up to 960H signals
• Advanced H.264 Linux embedded DVR
• 4-channels, real-time 30fps recording up to 5MP
• Up to 5MP recording resolution at 40fps
• PathFinder Peer-to-Peer (P2P) remote connection
• C3 CMS and event server software up to 288Channels
• Event camera group recording
• Complete system analysis with real-time system and network status monitoring
• Mobile Application for iPhone, iPad, iPod, Android Smart Phones and Tablets and Apple TV
• Mac compatible remote ACS software
• OSD and PTZ control via coax (UTC)
• Signal hybrid detects any camera at HD-Analog, HD-TVI and 960H automatically.
• Instant channel swap, no need to disconnect or reboot the DVR.
• Snapshot Notify: programmable interval snapshot notifications
• 4K (3840 x 2160) True HD, VGA and Spot video outputs
• 0TB - 16TB storage options
• HDD calculation and auto-recording configuration
• Thumbnail search with hour and 5-minute previews
• 10-second jump buttons for playback and fast forward
• Event notifications via email and C3 CMS and push notifications to mobile devices
• Multiplex - live, playback, recording, backup, network, configuration
• 4 audio input, 1 audio output
• 4 sensor input, 1 relay output
• Digital spot monitoring output at D1 resolution
• Simple and free DDNS service
• Push notifications via DW VMAX Plus app
• Add public view monitors with Spot Monitoring Modules
• Easy web-based client with multi-user access
• Help menu on major functions
• Auto and manual firmware upgrades
• 5 year limited warranty
