Advanced Linux-Based embedded NVR, 32TB, Supports 16 2.1MP cameras @30fps (1080P) up to 5MP, ONVIF, 16 port PoE switch built in, HDMI, VGA, 4 Sensor Input, 1 Relay Output, 1ch Audio Output, Pathfinder Auto Port Forwarding, Event Notifications via Email, Automatic Device Discovery, Pivot Central Management Software Up to 128CH, Free Mobile Apps for iPhone, iPad, iPod, Android Smart Phones and Tablets, MAC Compatible Remote Software, System Analysis with Real Time System, Network, and PoE Status Monitoring, Drag and Drop Camera Placement, One Touch Video Backup, Reverse Playback, & Emergency Recording, Simple & Free DDNS Support for Remote Management, Help Menu on Major Functions, Auto & Manual Firmware Upgrade Available, Import/Export Configuration between Multiple DVRs, USB Mouse and GUI Control, PTZ, 5 Year Limited Warranty
Features:
- Complete installation, setup and camera configuration in under three minutes!
- CCIP system encryption protects your surveillance system from out of network attacks
- Record and manage single-sensor IP cameras at real-time 30fps up to 4K (3840×2160), with 160Mbps maximum throughput
- Local power for up to 16 IP cameras via resident PoE switch
- myDW Cloud Management Services
- DW Witness turns a smartphone or tablet into an additional surveillance camera
- PathFinder Peer-to-Peer (P2P) remote connection
- Automatic device discovery
- Control any ONVIF camera’s setup and features remotely
- 2TB-32TB storage options
- Snapshot Notify: programmable interval camera image verification sent to an email
- Remote management with C3 CMS software up to 288 channels
- Event notifications via email, text and C3 CMS and push notifications to mobile devices
- Mobile Application for iOS and Android devices and Apple TV
- Dual-stream recording
- Easy drag and drop camera management
- Instant backup during playback
- 4K output for local live and playback display
- Complete analysis with real-time system, network and PoE monitoring
- True HD and VGA simultaneous output support
- 16 sensor inputs, 4 alarm relay outputs
- Advanced H.265, H.264 Linux embedded NVR
- NVR calculation and auto-recording configuration
- Add public view monitors with Spot Monitoring Modules
- Help menu on major functions
- Auto or manual firmware upgrade available
- Screen saver to protect monitor screen
- Import/export configuration between multiple NVRs
- USB mouse and GUI control
- 5 year limited warranty
| Operating system | Embedded Linux® | ||
| Video compression | H.265, H.264 | ||
| System | Channel | 16 channel | |
| Number of PoE | 16 Ch | ||
| Maximum resolution | IP camera maximum 4K (3840×2160) | ||
| Communication protocol | ONVIF® | ||
| PoE type | 1Gbps, 802.3at | ||
| Display | Speed | 480fps | |
| Screen mode | 1, 4, 9 and 16 | ||
| Video output | Monitor | True HD and VGA | |
| Resolution | 1024x768, 1280x720, 1280x1024, 1920x1080, 2560x1600, 3840×2160 (4K) | ||
| Recording speed | Up to 360fps up to 4K resolution | ||
| Maximum throughput | 160 Mbps | ||
| Maximum HDD bay | 4x HDDs, up to 32TB storage | ||
| Recording resolution | Dual-stream | ||
| Recording modes | Continuous, scheduled, sensor and motion detection, pre- and post-alarm, emergency, quick backup | ||
| Playback and search | Speed | x1, x2, x4, x8, x16, x32, x64, x99 | |
| Function | Timeline, calendar (date and time), event search, thumbnail search, smart motion search | ||
| Audio input/output | 1 output | ||
| Alarm input/relay output | 16 inputs/4 outputs | ||
| PTZ control | RS-485, ONVIF | ||
| Transaction verification | Text-in Based (USB to Serial support, TCP/IP Network) | ||
| LAN | Gigabit Ethernet (RJ45) | ||
| Access | Web viewer | Live, playback and configuration up to 10 multiple connections | |
| Client monitoring software | Mac®, C3 CMS, DW Mobile Plus mobile app | ||
| Backup device | Local backup by USB, network backup by CMS | ||
| System recovery after power failure | Auto-reboot and journaling file system | ||
| Other functions | Firmware upgrade | FTP, USB and CMS over Network | |
| Back-up | Import and export settings, watermark and AVI file backup | ||
| Special features | Local PoE switch Snapshot Notify: Programmable interval camera image verification sent to an email Event notifications via email, text and C3™ CMS and push notifications to mobile devices Real-time temp alert Digital zoom in live and playback | ||
| Mobile client | DW Mobile Plus app, DW Witness | ||
| Health check | Real-time system, network and PoE status monitoring | ||
| System operation | IR remote controller (sold separately), USB mouse, PTZ control by keyboard (optional) | ||
| Power requirements | 110~240V A/C | ||
| Power consumption | 300 W total power budget, 5.5A, 9.37W per PoE channel (simultaneous) | ||
| Total PoE power budget | 150W | ||
| Maximum power per port | 30W | ||
| Operating temperature and humidity | 41~104 °F (5~40 °C) / 20~90% RH | ||
| Certification | CE , FCC, KCC, WEEE, RoHS | ||
| Warranty | 5 year limited | ||
