Digital Watchdog - DW-VP16P - 16-Channel Plug and Play PoE NVR
Product Overview
The Digital Watchdog VMAX IP Plus is a powerhouse 16-channel PoE NVR designed for high-resolution 4K surveillance. It features 160 Mbps throughput and supports advanced H.265 compression, ensuring efficient storage of high-definition footage. With its 3-minute installation wizard and PathFinder P2P remote access, it eliminates the complexity of network setup, making it an ideal choice for both professional and DIY deployments.
Key Configuration
- • Channels: 16 IP camera inputs; PoE ports: 16 × 1Gbps (802.3at, 30W max per port, 150W total budget)
- • Max throughput: 160 Mbps; recording speed: up to 360 fps at 4K resolution
- • HDD: 4 × SATA bays, up to 32TB total storage
- • Video outputs: True HD (4K/3840×2160) and VGA simultaneous output; screen modes: 1, 4, 9, 16
- • Alarm: 16 inputs / 4 relay outputs; audio: 1 output; PTZ control: RS-485, ONVIF
Key Features
The VMAX IP Plus is an enterprise-grade 16-channel NVR designed for rapid deployment, capable of a full "three-minute" setup. It prioritizes data integrity through CCIP system encryption (TLS-secured RTSP streams) and utilizes PathFinder P2P for secure remote access without complex port forwarding. Unique to this system is DW Witness, which integrates mobile devices as live camera feeds, alongside advanced tools like Smart Motion Search and transaction verification for retail environments.
Technical Context
This NVR supports high-bandwidth 4K (3840×2160) recording and displays at a fluid 480 fps across its channels. It is built for 24/7 reliability with a journaling file system to prevent data loss after power failures and supports up to 10 simultaneous web connections. The unit manages a significant power load with a 300W total capacity, ensuring stable performance even when all 16 PoE ports are under heavy draw from high-powered cameras.
Installation Notes
The recorder features a 1.5U rack-mountable form factor (440 x 397,8 x 70 mm), making it suitable for standard server enclosures or desktop use. While a USB mouse is included for immediate GUI navigation, specialized controls like an IR remote or PTZ keyboard are available as separate accessories. It is designed for indoor operation, 41~104 °F, and includes a robust 5-year limited warranty, underscoring its long-term reliability in professional security racks.
| Operating system | Embedded Linux |
| Video compression | H.265, H.264 |
| Channel | 16 channel |
| Number of PoE | 16 Ch |
| Maximum resolution | IP camera maximum 4K (3840×2160) |
| Communication protocol | ONVIF |
| PoE type | 1Gbps, 802.3at |
| Speed | 480fps |
| Screen mode | 1, 4, 9 and 16 |
| Monitor | True HD and VGA |
| Resolution | 1024x768, 1280x720, 1280x1024, 1920x1080, 2560x1600, 3840×2160 (4K) |
| Recording speed | Up to 360fps up to 4K resolution |
| Maximum throughput | 160 Mbps |
| Maximum HDD bay | 4x HDDs, up to 32TB storage |
| Recording resolution | Dual-stream |
| Recording modes | Continuous, scheduled, sensor and motion detection, pre- and post-alarm, emergency, quick backup |
| Speed | x1, x2, x4, x8, x16, x32, x64, x99 |
| Function | Timeline, calendar (date and time), event search, thumbnail search, smart motion search |
| Audio input/output | 1 output |
| Alarm input/relay output | 16 inputs/4 outputs |
| PTZ control | RS-485, ONVIF |
| Transaction verification | Text-in Based (USB to Serial support, TCP/IP Network) |
| LAN | Gigabit Ethernet (RJ45) |
| Web viewer | Live, playback and configuration up to 10 multiple connections |
| Client monitoring software | Mac, C3 CMS, DW Mobile Plus mobile app |
| Backup device | Local backup by USB, network backup by CMS |
| System recovery after power failure | Auto-reboot and journaling file system |
| Firmware upgrade | FTP, USB and CMS over Network |
| Back-up | Import and export settings, watermark and AVI file backup |
| Special features | Local PoE switch Snapshot Notify: Programmable interval camera image verification sent to an email Event notifications via email, text and C3 CMS and push notifications to mobile devices Real-time temp alert Digital zoom in live and playback |
| Mobile client | DW Mobile Plus app, DW Witness |
| Health check | Real-time system, network and PoE status monitoring |
| System operation | IR remote controller (sold separately), USB mouse, PTZ control by keyboard (optional) |
| Power requirements | 110~240V A/C |
| Power consumption | 300 W total power budget, 5.5A, 9.37W per PoE channel (simultaneous) |
| Total PoE power budget | 150W |
| Maximum power per port | 30W |
| Operating temperature and humidity | 41~104 °F (5~40 °C) / 20~90% RH |
| Dimension (W x D x H) | 17.32” x 15.66” x 2.79” (440 × 397.8 ×70 mm), 1.5U |
| Certification | CE , FCC, KCC, WEEE, RoHS |
| Warranty | 5 year limited |
