CCIP System Encryption
The CCIP (Closed Circuit IP) encryption is activated when the VMAX IP G4 system sends a request for an encrypted stream from the camera. The camera then encrypts its RTSP stream a second time using TLS, using the encryption's user ID and password. The result is a secured and encrypted RTSP stream that can be read only by the requesting recorder.
3-minute installation
The entire system can be set up and configured in less than four minutes from power-up. Using the user-friendly startup wizard, configure the NVR’s main functions, locate and register all your cameras and set them to record in less than four minutes and with no need for a technical background!
C3 CMS
C3 CMS takes video management to the next level. You are in complete command to control all your video surveillance systems in one intuitive interface. Easy-to-program alerts let you take action in real-time and manage the health of your devices.
PathFinder
Easy and secure remote connection with NAT Traversal (STUN/TURN) support without opening ports.
Push notifications via DW Mobile Plus App
DW’s recorders can send an event notification to your mobile device via the DW Mobile Plus app.
Features:
- Complete installation, set up and camera configuration in under three minutes!
- CCIP system encryption protects your surveillance system from out of network attacks
- Record and manage single-sensor IP cameras up to 4K (3840×2160), with 80Mbps maximum throughput
- Local power for up to 4 IP cameras via resident PoE switch
- DW Witness turns a smartphone or tablet into an additional surveillance camera
- PathFinder Peer-to-Peer (P2P) remote connection
- HTTPS encryption supported
- Automatic device discovery
- Control any ONVIF camera’s set up and features remotely
- 0TB-32TB storage options
- Snapshot Notify: camera notifications sent to an email or CMS
- C3 CMS and event server software up to 144 Channels
- Event notifications via email, text and C3 CMS and push notifications to mobile devices
- Mobile application for iPhone, iPad, iPod, Android smartphones and tablets and Apple TV
- Dual-stream recording
- Easy drag and drop camera management
- Instant backup during playback
| Video | |
|---|---|
| Display Modes | 1, 4, 9, Sequence |
| Display Speed | Up to 30fps per channel |
| Local Video Output Resolution | 1024x768, 1280x1024, 1280x720, 1920x1080, 2560x1600, 3840×2160 (4K) |
| Local Video Outputs | True HD, VGA |
| Max Supported Recording Resolution | 4K (3840×2160) |
| PoE Type | 100Mbps, 802.3at |
| Video Compression | H.264 |
| OS on SSD | 2x SSD (RADI1 mirrored) |
| Max throughput (Mbps) | 80Mbps |
| Input channels | 4 PoE channels, 9 Channels |
| Storage | |
| HDD healthcheck | Temperature, S.M.A.R.T. with email notifications |
| Max HDD Bay | 2 x SATA HDD |
| Maximum Storage | 12TB (DW-VP912T-4P), 16TB (DW-VP916T-4P), 2TB (DW-VP92T-4P), 4TB (DW-VP94T-4P), 6TB (DW-VP96T-4P), 32TB (DW-VP932T4P), No storage (DW-VP9P) |
| Performance | |
| Audio in/out | 1 input, 1 output |
| Performance features | AVI file backup, Camera Color Control, CCIP, Covert Channel, Digital Zoom in live and playback, Import and export settings, PoE built-in, Quick Setup under 3 Minutes, Real-time temp alert, Snapshot Notify: Programmable interval camera image verification sent to an email, Watermak exported video |
| Playback Functions | Calendar, Event search, Smart motion search, Thumbnail search, Timeline |
| Playback speed | x1, x16, x2, x32, x4, x64, x8, x99 |
| Post-recording | 0~5 minutes |
| Pre- recording | 0~5 seconds |
| PTZ control | ONVIF, RS485 |
| Recording Modes | Continuous, Emergency, Motion detection, Pre- and post-alarm, Quick backup, Scheduled, Sensor |
| Recording Resolution and Recording Rate | Up to 3840×2160 (4K): 270fps, Up to 3840×2160 (4K): 360fps, Up to 3840×2160 (4K): 480fps |
| System Operation | Graphical user interface (GUI), Joystick Controller (optional), Remote Control (optional), USB mouse (included) |
| Network | |
| Backup | Local backup via USB, Network backup via CMS |
| Ethernet Ports | 1x 1G Ethernet (RJ45) |
| Firmware Upgrade | CMS over network, FTP, USB |
| Protocol | DDNS, DHCP, RTSP, Static fixed IP, uPNP |
| System recovery after power failure | Auto-reboot and journaling file system |
| Transation verification | Text-in Based (USB to Serial support, TCP/IP Network) |
| Transmission speed live | Up to 3840×2160 (4K): 270fps |
| Network Remote Software | DW VMAX Plus App, ACS VMAX Client for MAC, C3 CMS, DW Mobile Plus, DW VMAX App, DW Witness, Pivot CMS |
| Electrical | |
| Maximum Power per Port | Up to 30W |
| Power Consumption | 19W per PoE channel, simultaneous, 90W total power budget, 1.875A, A UPS is recommended |
| Power Requirements | 48V AC |
| Total PoE Power Budget | 76W |
| General | |
| Accessories | IR remote control (optional), Mouse |
| Operating Temperature and Humidity | 20 ~ 90% RH, 41 ~ 104 °F (5~40 °C) |
| Rail kit | DW-VAP19RE - 19" rackmount ears |
| Recorder Dimensions (H X W X D) | 14.96" x 12.4" x 2.02" (380 × 315 × 51.5 mm) |
| Serial ports | RS485 |
| USB interface | Yes |
| Warranty | 5 Year Limited Warranty |
| Form Factor | Embedded |
