Digital Watchdog - DWC-XSBF08LiF - 4K Network IP Bullet Camera with 6-22mm Lens
• Proactive Deterrence: Built-in white light illumination, flashing red/blue LEDs, and a 14-watt speaker actively deter intruders before incidents occur.
• Smart Ai Detection: AI analytics with up to 40 customizable detection zones reduce false alarms and improve response accuracy.
• Exceptional Image Quality: 4K resolution at 30fps, Star-Light Plus™ technology for color in near-total darkness, and True WDR deliver clear, detailed footage in any lighting.
• Flexible Lens Control: Motorized 6–22mm vari-focal P-Iris lens with autofocus allows remote zoom and precise image tuning.
• Efficient Bandwidth & Storage: Triple codec support (H.265, H.264, MJPEG) and smart recording optimize storage and streaming.
• Two-Way Audio: Built-in microphone and speaker enable direct communication between the monitoring station and the camera location.
• Easy Integration: Compatible with DW Spectrum® and OnVIF, plus alarm input/relay output for access control systems.
• Rugged & Compliant: IP66 and IK10 rated for harsh environments, NDAA/TAA compliant for government use, and backed by a 5-year warranty.
| Image | |
| Color temperature | Warm light 3300K |
| WL wavelength (lumen) | 200lm |
| Active Pixels | 3840 (H) x 2160 (V) |
| Frequency | 50Hz |
| Image sensor | 4K 1/2.8" CMOS sensor Star-Light Plus™ sensor |
| Maximum resolution | 4K |
| Minimum Scene Illumination in color | 0.0 lux (B/W) 0.12 lux (color) |
| Test Video Output | Local video output CVBS 1.0V p-p (75Ω), 16:9 aspect ratio |
| Total Pixels | 3864(H) x 2228(V) |
| Lens | |
| Advanced Lens Features | Auto focus Motorized zoom P-iris |
| Focal Length | 6 - 22mm |
| Horizontal Field of View (HFOV) | 49.3° - 18.1° |
| Illumination Distance | 130' range Smart IR™ |
| Lens Type | Vari-focal Lens |
| Vertical Field of View (VFOV) | 10.2° - 24.3° |
| I/O | |
| Event triggers | Illegal login Motion Alarm Network disconnection Schedule Sensor detection Temperature anomaly |
| I/O Alarm in/out | 1 input 1 output |
| I/O Audio in/out | 1 audio input selectable at a time 14-watt speakers built-in 1 input 1 microphone built-in |
| Intelligent Video Analytics | |
| Advanced video analytics | AI-based object tracking |
| Analytics filters | Zones and lines, tamper, metadata, intrusion, line crossing, counting, counting lines, appear, disappear, stopped, enter, exit, direction, tailgating, dwell, logical rules |
| Operational | |
| 3D digital noise reduction | Smart DNR™ 3D Digital Noise Reduction |
| Auto gain control | Auto |
| Day and night | Auto day/night Day (color) Night (B/W) |
| De-fog | Yes |
| Memory slot | Micro SD/SDHC/SDXC class 10 card (card not included) Up to 1TB micro SD / FAT32 |
| Mirror/flip | Yes |
| Motion Detection | Yes |
| Operational Notifications | Alarm output activation FTP server SD card recording |
| Privacy Zones | 16 programmable privacy masks |
| Sharpness | Yes |
| Shutter Mode | Anti-Flicker Auto Manual Slow Shutter |
| Shutter Speed | 1/15 ~ 1/32000 |
| Slow Shutter Speed | Off x10 x2 x3 x4 x5 x6 x7.5 |
| White Balance | Yes |
| Wide Dynamic Range (WDR) | True WDR 120dB |
| Network | |
| Bitrate Control | Multi-streaming CBR/VBR at H.264, H.265 (controllable frame rate and bandwidth) |
| IP | IPv4 |
| LAN | 1000Base-T (1Gbps) |
| Network resolution | H.264: 3840x2160, 2592x1944, 2560x1440, 1920x1080, 1280x720, 640x480, 640x360, 352x288, 352x240 H.265: 3840x2160, 2592x1944, 2560x1440, 1920x1080, 1280x720, 640x480, 640x360, 352x288, 352x240 MJPEG: 1920x1080, 1280x720, 800x600, 768x432, 704x576, 704x480, 640x480, 640x360, 352x288, 352x240 |
| Network Web Viewer | Google Chrome® browser Linux® OS Mac® OS Microsoft Edge® browser Mozilla Firefox® browser Safari® browser Windows OS |
| Protocol | DDNS, DHCP, DNS, FTP, HTTP, HTTPs, ICMP, NTP, ONVIF, RTP (UDP/TCP), RTSP, SMTP, SNMPv1/v2/v3 (MIB-2), SSL, TCP/IP, UDP, Zeroconf (AutoIP) |
| Security | 802.1x Digest authentication (ID/PW) HTTPS (TLS) IP filtering |
| Stream Speed | Up to 30fps at all resolutions |
| Streaming Capability | Triple Streaming (3rd stream MJPEG only) |
| Video Bitrate | 100Kbps ~ 25Mbps, multi-rate for preview and recording |
| Video Compression Type | H.264 H.265 MJPEG |
| Video Management Software | Any ONVIF conformant CMS DW Spectrum® |
| Environmental | |
| Compliance | CE FCC NDAA Comp ONVIF TAA Compliance UL Listing |
| Environmental Operating Humidity | 10-90% (non-condensing) |
| Environmental Operating Temperature | -4°F ~ 122°F (-20°C ~ 50°C) |
| Mounting Accessories (Required/Optional) | Optional. Sold separately |
| Mechanical | |
| Camera Dimensions (H X W X D) | 10.23" x 10.19" x 6.14" (260 x 259 x 156mm) |
| Camera Weight | 8.15 lbs (3.7 kg) |
| Housing | Bullet |
| Housing Color | White |
| IK rating | IK10 Rated |
| IP rating | Weather Resistant (IP66) |
| Materials | Aluminum die-casting |
| Electrical | |
| American wire gauge (AWG) | 5M Cable type #18 |
| Power Requirements | High power PoE injector included PoE |
| General | |
| Warranty | 5 Year Warranty |
This NDAA/TAA-compliant 4K bullet camera features edge AI technology, two-way audio and powerful multi-colour deterrent LEDs. Its high-intensity lighting and clear audio alerts proactively deter intruders while capturing detailed video footage.
