Digital Watchdog - DWC-XSTD08MF - 4K MEGApix Ai Indoor/Outdoor Vandal Turret Camera Star-Light Plus, 3.6-10mm Lens
• Proactive Deterrence - White light illumination and red/blue flashing LEDs actively deter intruders before incidents occur.
• High-Quality Imaging - 4K resolution at 30fps with Star-Light Plus™ technology delivers clear color video even in near-total darkness.
• AI-Powered Accuracy - Deep learning object detection with up to 40 detection zones reduces false alarms and improves threat identification.
• Smart Storage Efficiency - Intelligent recording logic minimizes unnecessary footage, saving bandwidth and storage costs.
• Remote Lens Control - Motorized vari-focal p-iris lens with autofocus allows precise zoom and focus adjustments from anywhere.
• Seamless Integration - Native compatibility with DW Spectrum ensures smooth system management and control.
• Two-Way Audio - Built-in mic and speaker enable real-time communication between the camera site and monitoring station.
• Privacy Protection - Configurable privacy zones help comply with regulations and protect sensitive areas.
• Reliable Operation - IP67 and IK10-rated housing ensures durability in harsh environments, backed by a 5-year warranty.
• Government-Ready Compliance - NDAA and TAA compliance makes it suitable for federal and government installations.
| IMAGE | |
| Image sensor | 8.48MP 1/1.8" Star-Light Plus™ sensor |
| Total pixels | 3856(H) X 2200(V) |
| Active pixels | 3840 (H) X 2160 (V) |
| Minimum scene illumination | 0.035 lux (color) 0 lux (white light) |
| Color temperature | Warm light, 3300K |
| WL wavelength (lumen) | 200lm |
| S/N ratio | 50dB |
| LENS | |
| Focal length | 3.6~10mm F1.5 |
| Lens type | Vari-focal p-iris lens with motorized zoom and auto-focus |
| Horizontal Field of view (HFoV) | 45.7°~98.4° |
| Vertical Field of view (VFoV) | 25.9°~54.6° |
| IR distance | 90ft range white light |
| Optical zoom / digital zoom | 2.7x optical zoom |
| I/O | |
| Audio input/output | 1 microphone built-in/ 1 speaker built-in |
| Audio compression | G.711 ulaw |
| Alarm input/output | 1 input/1 output |
| Event trigger | Motion alarm, network loss, temperature anomaly, illegal login, schedule, sensor detection |
| INTELLIGENT VIDEO ANALYTICS | |
| AI-based video analytics | AI-based object and people detection, classification and tracking |
| Analytics filters | Zones and lines, tamper, metadata, intrusion, line crossing, counting, counting lines, appear, disappear, stopped, enter, exit, direction, tailgating, dwell, logical rules |
| OPERATIONAL | |
| Shutter mode | Auto, manual, anti-flicker, slow shutter |
| Shutter speed | 1/15 ~ 1/32000 |
| Slow shutter | 1/2, 1/3, 1/5, 1/6, 1/7.5, 1/10 |
| Auto gain control | Auto |
| Day and night | Color only |
| 3D Digital Noise Reduction | Smart DNR™ 3D-DNR |
| Wide Dynamic Range (WDR) | True WDR |
| Wide Dynamic Range (WDR) dB | 120dB |
| White balance | Yes |
| Privacy zones | 16 programmable privacy masks |
| Mirror and flip | Yes |
| Alarm notifications | Notifications via email, FTP, alarm output, SD card recording and flashlight |
| Memory slot | Micro SD/SDHC/SDXC class 10 card (not included) |
| NETWORK | |
| LAN | 1000Base-T (1Gbps) |
| Video compression type | H.265, H.264, MJPEG |
| Resolution | H.265: 3840x2160, 2592x1944, 2560x1440, 1920x1080, 1280x720, 640x480, 640x360, 352x288, 352x240 H.264: 3840x2160, 2592x1944, 2560x1440, 1920x1080, 1280x720, 640x480, 640x360, 352x288, 352x240 MJPEG: 1920x1080, 1280x720, 800x600, 768x432, 704x576, 704x480, 640x480, 640x360, 352x288, 352x240 |
| Frame rate | Up to 30fps at all resolutions |
| Video bitrate | 100Kbps ~ 25Mbps, multi-rate for preview and recording |
| Bitrate control | Multi-streaming CBR/VBR at H.265 (controllable frame rate and bandwidth) |
| Streaming capability | Triple Streaming (3rd stream MJPEG only) |
| IP | IPv4 |
| Protocol | TCP/IP, UDP, AutoIP, RTP(UDP/TCP), RTSP, NTP, HTTP, HTTPS, SSL, DNS, DDNS, DHCP, FTP, SMTP, ICMP, SNMPv1/v2/v3(MIB-2), ONVIF |
| Security | HTTPS (TLS), IP filtering, 802.1x, digest authentication |
| ONVIF conformance | Yes |
| Web viewer | OS: Windows OS, Mac OS, Linux OS Browser: Microsoft Edge, Google Chrome, Mozilla Firefox, Safari |
| Video management software | DW Spectrum |
| ENVIRONMENTAL | |
| Operating temperature | -4°F ~ 122°F (-20°C ~ 50°C) |
| Operating humidity | 10–90% RH, (non–condensing) |
| IK rating | IK10 impact-resistant |
| IP rating | IP67-rated |
| Other certifications | CE, FCC, UL, NDAA, TAA |
| ELECTRICAL | |
| Power requirement | DC12V, PoE, adapter not included |
| Power consumption | 12V DC: 12W, 1A ; PoE: 15W, 312.5mA |
| MECHANICAL | |
| Material | Aluminum vandal housing, polycarbonate lens cover |
| Dimensions | 4.92" x 4.79" (125 x 121.7 mm) |
| Weight | 1.94 lbs (0.88 kg) |
| Warranty | |
| Warranty | 5 year warranty |
This NDAA/TAA-compliant 4K turret camera provides an active deterrent in the form of a built-in white light and red/blue flashing LEDs, as well as edge AI object classification. With two-way audio and alarm functions, it provides a comprehensive real-time response solution.
