ELK - AEXCELLV - Alarm Engine Cellular Communicator for for Verizon LTE Network

Product Overview

The ELK-AEXCELLV is an Alarm Engine cellular communicator for Verizon LTE network connectivity. It enables ELK E27 Alarm Engine controls to communicate with a central station and provides a cellular communication path for remote interactive services and programming when the IP pathway is unavailable.

Key Configuration

Verizon LTE cellular communicator for ELK Alarm Engine systems; connects to the RS485 data bus on the E27 control board; requires E27 firmware version 0.6.2 or later; requires an active ElkConnect IP Interactive with Cellular subscription plan.

Key Features

• Provides alarm and event reporting to a central station
• Automatically switches to cellular communication when the IP path is inaccessible
• Supports remote interactive services and system programming through ElkConnect
• Uses ElkConnect interactive services over cellular with no added cellular cost
• Quick setup with automatic bus enrollment and minimal programming required

Technical Context

The AEXCELLV connects to the E27 RS485 data bus to provide Verizon LTE cellular backup for Alarm Engine communications. If the primary IP pathway becomes unavailable, the E27 control can automatically use the cellular pathway for central station reporting and supported ElkConnect services.

Installation Notes

The communicator requires an E27 control running firmware version 0.6.2 or later and an active ElkConnect IP Interactive with Cellular plan. Activation and setup are managed through the ElkConnect portal after connection to the E27 RS485 data bus.
