ELK - C1M14GSM - ELK C1M14GSM Dual-Path Alarm Communicator, GSM Version

Product Overview

The ELK-C1M1LTEV is a dual-path IP and cellular communicator designed for ELK M1 control systems. It provides fast central station reporting, remote access, installer programming, and user notifications without relying on dial capture, data bus decoding, or cloud server relays.

Key Configuration

Dual-path communicator for ELK M1 controls; supports IP and cellular reporting pathways; connects directly to the M1 Control; supports ElkRP2 programming upload and download over IP or cellular pathways; supports remote access with no port forwarding or extra fees.

Key Features

• Provides dual reporting pathways over IP and cellular
• Automatically directs transmissions over the first available or best pathway
• Sends periodic tests over both pathways to verify communication reliability
• Supports remote control through a web portal and the free ElkLink mobile app
• Provides email and push alerts for arm, disarm, and alarm events

Technical Context

The C1M1LTEV connects directly to the M1 Control to reduce communication delays associated with dial capture or data bus decoding. It can report a pathway outage over the remaining communication path, helping maintain central station connectivity when either IP or cellular service is disrupted.

Installation Notes

Installers can activate and manage C1M1 communicators and remotely program the M1 control over either the IP or cellular pathway. The communicator also supports third-party apps including eKeypad for iOS and M1 Touch Pro for Android.
