ExacqVision - HDD-04T-JBOD - Internal 4TB Surveillance Hard Drive
Part number:
Price:
- • 4TB Capacity: Provides approximately 4,000GB of raw storage space. In a standard 1080p environment, this can typically hold several weeks of continuous footage from multiple cameras, depending on the frame rate and compression.
- • JBOD Configuration: The "JBOD" (Just a Bunch of Disks) designation means this drive is intended for systems without RAID redundancy. It is the standard storage SKU for entry-level and mid-range recorders where maximum usable space is prioritized over data mirroring.
- • Surveillance-Grade Firmware: Unlike standard "desktop" or "PC" hard drives, this unit is engineered for a 90% write / 10% read duty cycle. It can handle the constant, simultaneous writing of dozens of video streams without overheating or skipping frames.
- • Compatibility: Specifically validated for exacqVision A-Series (2A) and Q-Series NVRs. It is also compatible with many Digital Watchdog Blackjack units as a primary or expansion drive.
- • Factory-Only Restriction: Like the other internal hardware we've discussed, this is not field-upgradeable. It must be installed at the factory at the time of purchase to ensure it is properly partitioned and formatted within the exacqVision Linux or Windows environment.
| Model | HDD-04T-JBOD |
| Capacity | 4TB (Surveillance-Grade) |
| Drive Interface | SATA 6Gb/s |
| Configuration | JBOD (Just a Bunch Of Disks / Non-RAID) |
| Compatible Series | exacqVision A-Series 2A, Q-Series |
| Installation | Factory-installed only |
Name
Description
Size
Downloads
File
Spare Hard Drives For A-Series
0.9mb
