ExacqVision - HDD-08T-RAID - Internal 8TB Enterprise-Grade Surveillance Hard Drive
Part number:
Price:
- • 8TB Capacity: Provides 8,000GB of raw storage per drive. When used in a RAID array (such as RAID 5 or RAID 6), these drives work together to provide a massive, protected pool of video data.
- • RAID-Optimized Firmware: Unlike the "JBOD" version, the "RAID" SKU features specialized Time-Limited Error Recovery (TLER). This prevents the drive from "falling out" of an array if it encounters a minor read error, ensuring your recording volume stays online.
- • High-Workload Rating: These drives are typically rated for 550TB per year of data transfer, making them significantly more durable than standard surveillance drives. They are designed to handle the vibration and heat of being packed into a multi-bay 1U or 2U rackmount server.
- • Compatibility: Specifically validated for exacqVision A-Series (FA/FAR) and X-Series recorders. These enterprise servers require these specific "RAID" SKUs to function with their hardware RAID controllers.
- • Factory-Only Installation: This is not field-upgradeable. To ensure the RAID array is properly striped, parity-checked, and initialized, these drives must be installed and configured at the factory during the initial server build.
| Model | HDD-08T-RAID |
| Capacity | 8TB (Enterprise-Grade) |
| Drive Interface | SATA 6Gb/s or SAS |
| Configuration | RAID-Ready (Optimized for RAID 5/6) |
| Compatible Series | exacqVision A-Series FA/FAR, X-Series |
| Installation | Factory-installed only |
Name
Description
Size
Downloads
File
Spare Hard Drives For A-Series
0.9mb
File
A&E Specification
0.1mb
File
Specsheet
0.5mb
