Elevate your visual experience with our state-of-the-art Flex Gen4 Indoor Mini Dome, powered by deep learning AI and designed for perfection. This camera transcends ordinary imaging capabilities, offering unparalleled enhancements in challenging conditions, including low light, thanks to its Flex AI suite—calibrated right out of the box. Smart bandwidth management ensures smooth operation without sacrificing quality, while its smart screwless design and smoked bubble aesthetic make it a stylish addition to any space. Compatibility is never an issue with an open standard interface, including Onvif Profile S, G, T, M conformity, ensuring seamless integration into existing systems. Engineered for efficiency, it boasts low power consumption and advanced security features to protect your data, alongside power failover support for uninterrupted operation. Adhering to JCI cyber norms, this camera promises not just superior performance but also peace of mind with a 5-year warranty, making it a smart, secure, and environmentally friendly choice for discerning users who demand the best in imaging technology.
Features:
- Flex AI suite enabled & calibrated out of the box
- Outstanding imaging in low light conditions
- Corridor and dual HD streaming mode
- Smart screwless design with smoked bubble
- Onvif Profile S, G, T, M conformant
- Power Edge AI for Improved Security and Efficiency
- Power failover support
- Conforms to JCI cyber norms
| Camera Features | Flex Gen4 Indoor Mini Dome Camera |
| AI Object Classification | Classes: Person, Bicycle, Bus, Car, Motorbike, Train, Truck, Any Class Sub-Classes (attributes): Person Clothing Color (Upper, Lower), Vehicle Color Rules: Object Detected, Perimeter, Linger, Dwell, Abandoned/Removed, Enter, Exit, Crowd, Queue, Direction |
| Audio | Bi-directional, 1x Line input and 1x Line output |
| Alarm Input/Output | 1x Alarm In and 1x Alarm Out |
| Day/Night | True Day/Night CF removal |
| Defog | Supported |
| Dimensions | Ø132 x 98 mm (Ø5.2 x 3.9 in) |
| Dynamic Range | True multi shutter WDR up to 141 dB Off, TWDR, TWDR 3x, SmartWDR |
| Environment Rating | IEC 62262 IK08 BS EN IEC 63000 ROHS, REACH, WEEE |
| Ethernet | IEEE 802.3, 10/100Base-T Ethernet, RJ45, auto sensing |
| Field of View | 2MP: H: 98.47°(W) – 31.1°(T) V: 51.88°(W) – 17.55°(T) 5MP: H: 97.57°(W) – 31.74°(T) V: 70.26°(W) – 23.84°(T) 8MP: H: 112.1°(W) – 47.5°(T) V: 58.0°(W) – 26.6°(T) |
| H.264 | yes |
| H.265 | yes |
| Housing Color | Signal White Pantone RAL 9003 |
| Imager | 2MP: Sony 1/2.8” Progressive Scan CMOS imager 5MP: Sony 1/2.8” Progressive Scan CMOS imager 8MP: Sony 1/1.8” Progressive Scan CMOS imager |
| Lens Type | 2MP: 2.7 mm – 13.5 mm, MFZ, P-Iris, F1.6(W) – F3.1(T) 5MP: 2.7 mm – 13.5 mm, MFZ, P-Iris, F1.31(W) – F2.37(T) 8MP: 3.6 – 11mm, MFZ, P-iris, F1.3(W) – F2.15(T) One touch auto focus, manual, and automatic focus with zoom |
| Max Frame Rate | 2MP: 60/50 fps 5MP: 30/25 fps 8MP: 15/12.5 fps |
| Minimum Illumination | 2MP: Color: 0.05 lux, B/W: 0.005 lux 5/8MP: Color: 0.1 lux B/W: 0.01 lux |
| MJPEG | yes |
| Motion Detection | 3 zones supported |
| Onboard Storage | microSDXC slot, Class 10 or better, upto 1TB supported (Card not included) Pre event / Post event 1- 10 sec Encrypted storage and streaming TrickleStor offline recording and backfilling |
| ONVIF Compliant | S, G, T, M |
| Operating Temperature | -20°C (-4°F) to +60°C (140°F) Start-up temperature: -20°C (-4°F) up to 90% RH, Non-Condensing |
| Pan Travel | Pan 350°, Tilt 67°, Rotation 355° |
| Power Draw | 2MP: PoE Typ. 0.1A / Max 0.15A Typ. 4.5W / Max 7.1W 24VAC Typ. 0.38A / Max 0.56A Typ. 4.7W / Max 7.4W 5MP: PoE Typ. 0.11A / Max 0.16A Typ. 5.2W / Max 7.5W 24VAC Typ. 0.43A / Max 0.59A Typ. 5.4W / Max 7.8W 8MP: PoE Typ. 0.12A / Max 0.19A Typ. 5.5W / Max 8.7W 24VAC Typ. 0.45A / Max 0.67A Typ. 5.7W / Max 9.0W |
| Power Input | PoE 802.3af (802.3at Type 1) Class 3 | 24VAC |
| Privacy Zones | 10 user definable rectangular zones |
| Resolution Options | 2MP: 16:9: 1920 x 1080 (2MP) to 480x272 5MP: 4:3: 2560 x 1920 (5MP) to 480x272 8MP: 16:9: 3840 x 2160 (8MP) to 480x272 |
| Shutter Speed | Automatic, Manual (1/4 to 1/32000 sec) |
| Simultaneous Users | 10 users |
| Supported Protocols | TCP/IP, IPv4, IPv6, TCP, UDP, HTTP, FTP, DHCP, WS-Discovery, DNS, DDNS, RTP, RTCP, RTSP, TLS, Unicast, Multicast, NTP, ICMP, IGMP, SMTP, WS-Security, IEEE 802.1x, PEAP, EAP-TLS, EAPoL, SSH, HTTPS, SOAP, WS-Addressing, CIFS, UPNP, LLDP, SIP, ARP, EAP-LEAP, QoS |
| Video Streams | Triple Streaming with a maximum of 5 concurrent shared streams |
| Weight | Net 0.43kg (0.95 lbs.), Gross 0.70kg (1.54 lbs.) |
| Wi-Fi | Micro USB via optional USB Wi-Fi Dongle IA-KIT-WD-UUA |
