IP04-02T-GP08
Part number:
IP04-02T-GP08
Price:

The G-Series PoE offers sophisticated performance from a cost-effective NVR without the hassle of wiring cameras to a power supply. Equipped with a generous PoE budget, this NVR delivers 15 watts simultaneously on all ports, and up to 30 watts on any port, giving customers substantial flexibility on camera choices, with a simple plug-and-play setup.

Powerful local client performance means that live video can be viewed directly on the NVR with 8 full-HD simultaneous streams at 15fps, providing a high-quality experience when viewing live or searching stored video.



Features:



Safeguard Against Cyber Attacks Across Devices

exacqVision G-Series NVRs have been designed to be resilient against cyber-threats. This solution includes role based access control that allows administrators to restrict access to functions and cameras by user role. Safeguard controls include an enhanced security mode which forces the use of complex, non-default password and encrypted communications. G-Series NVRs adheres to the rigorous standards of the Johnson Controls Cyber Solutions Product Security Program. The holistic approach to cyber protection is aimed at providing peace of mind to our customers. Our security mindset begins at initial design concept and is supported through deployment, including a rapid incident response to meet the comprehensive and evolving cybersecurity environments.



3-Year Warranty and Software Subscription Agreement (SSA)

  • Constantly increase VMS features with regular software updates
  • 3 years of unlimited software updates included
  • 3 years of system warranty
IPG-Series PoE 4-PortG-Series PoE 8-PortG-Series PoE 16-Port
Maximum PoE Cameras4816
Included IP Licenses2 PRO4 PRO4 PRO
PoE Power15 W (all ports simultaneously)
30 W max (individual port)
60 W (total)
15 W (all ports simultaneously)
30 W max (individual port)
120 W (total)
15 W (all ports simultaneously)
30 W max (individual port)
240 W (total)
Pre-Loaded VMS SoftwareProfessional
Enterprise (Optional)
Professional
Enterprise (Optional)
Professional
Enterprise (Optional)
Include SSA3 Years3 Years3 Years
Operating SystemLinux Ubuntu 18.04Linux Ubuntu 18.04Linux Ubuntu 18.04
Maximum Storage4 TB12 TB12 TB
Maximum Hard Drives111
Typical Video Storage Rate60 Mbps60 Mbps120 Mbps
Local Client Display Rate (1080p)4 streams @ 15 FPS each8 streams @ 15 FPS each16 streams @ 15 FPS each
CPUIntel AtomIntel AtomIntel Atom
RAM4 GB4 GB4 GB
Monitor OutputDisplay Port, HDMI
2 Simultaneous
Display Port, HDMI
2 Simultaneous
Display Port, HDMI
2 Simultaneous
NIC2 x 1 Gbps2 x 1 Gbps2 x 1 Gbps
USB2 USB 2.0 Front, 2 USB 3.0 Rear2 USB 2.0 Front, 2 USB 3.0 Rear2 USB 2.0 Front, 2 USB 3.0 Rear
Audio Input111
Audio Output111
DVDExternal (Optional)External (Optional)External (Optional)
AccessoriesKeyboard (on-screen), MouseKeyboard (on-screen), MouseKeyboard (on-screen), Mouse
Dimensions (H x W x D)1.73 in x 10.82 in x 8.67 in
4.4 cm x 27.5 cm x 22 cm
1.73 in x 10.82 in x 8.67 in
4.4 cm x 27.5 cm x 22 cm
1.73 in x 12.6 in x 11.02in
4.4 cm x 32 cm x 28 cm
Weight6 lbs
2.72kg
6 lbs
2.72kg
10 lbs
4.54 kg
GeneralG-Series PoE 4-PortG-Series PoE 8-PortG-Series PoE 16-Port
Regulatory
Input Voltage56V-DC, 1.8A
Auto-Sensing
56V-DC, 3.2A
Auto-Sensing
56V-DC, 5.53A
Auto-Sensing
Power SuppliesSingleSingleSingle
Power & Heat100 Watts/342 BTU/h (Max)
23 Watts/78 BTU/h + POE Usage (Typical)
180 Watts/614 BTU/h (Max)
23 Watts/78 BTU/h + POE Usage (Typical)
310 Watts/ 1058 BTU/h (Max)
70 Watts/239 BTU/h + POE Usage (Typical)
Operating Temperature32° - 104°F
0° - 40°C
32° - 104°F
0° - 40°C
32° - 104°F
0° - 40°C
Warranty3 Years3 Years3 Years
