ExacqVision - IP08-01T-GML-E - 1TB Micro G-Series IP Desktop NVR Enterprise Linux with 8 IP Professional licenses (8 max)
Part number:
IP08-01T-GML-E
Price:

IP Desktop Micro G-Series exacqVision NVR with 8 IP Enterprise licenses (8 max), 1TB SSD storage. Linux Ubuntu 22.04 LTS OS on SSD, 8GB RAM, 1 X 1GbE, 1 x 2.5GbE, 8 x USB, 2 x DP. Includes VESA mount kit, mouse and keyboard. Pre-installed exacqVision VMS software with 3 year SSA and 3 year RMA hardware warranty.



Features:

G-Series Micro

  • The G-Series Micro is a video recording solution designed for customers who want to leverage concise camera counts in an ultra small form factor. The Micro is a great combination for exacqVision Cloud Drive or other cloud storage options giving customers an economical options to store, access and search critical surveillance video for up to 8 IP cameras.



Small and Mighty

  • As small in stature as it is in price, the G-Series Micro fits perfectly in space-constrained applications such as retail shops, restaurants, banks, and other small professional offices. The G-Series Micro flexibility and targeted approach to NVR storage device is perfect to scenarios with limited camera counts or distributed architecture.



Safeguard Against Cyber Attacks Across Devices

  • ExacqVision G-Series NVRs have been designed to be resilient against cyber-threats. This solution includes role based access control that allows administrators to restrict access to functions and cameras by user role. Safeguard controls include an enhanced security mode which forces the use of complex, non-default password and encrypted communications. G-Series NVRs adheres to the rigorous standards of the Johnson Controls Cyber Solutions Product Security Program. The holistic approach to cyber protection is aimed at providing peace of mind to our customers. Our security mindset begins at initial design concept and is supported through deployment, including a rapid incident response to meet the comprehensive and evolving cybersecurity environments.



3-Year Warranty and Software Subscription Agreement (SSA)

  • Constantly increase VMS features with regular software updates
  • 3 years of unlimited software updates included
  • 3 years of system warranty
IP SettingsG-Series Micro NVR
IP CompressionH.265/H.264/MJPEG
Video Throughput120Mbps (Linux)
Maximum IP StreamsUp to 8
Included Camera Licenses8 (Professional or Enterprise),
3-year SSA included
exacqVision Advantage w/Illustra included
Alarm Inputs/OutputsUSB I/O Module
(sold separately)
ServerG-Series Micro NVR
Form FactorUltra Small Form Factor (USFF)
Maximum Hard Drives1 Internal Drive
Maximum Storage1TB High Endurance SSD
Monitor Output(2) Display Ports
*DP to HDMI adapter included
Local Client Display Rate540 FPS @ 1080p Resolution (Linux)
Operating SystemUbuntu Linux 22.04
Operating System Location256GB, SSD
CPUCeleron
RAM8GB
NIC1 x 1.0 Gbps, 1 x 2.5 Gbps
GeneralG-Series Micro NVR
DimensionsD: 177.8mm (7 in)
W: 177.8mm (7 in)
H: 50.8mm (2 in)
Power120W (max)
120-240vac
Cooling(1) Internal Fan
Weight1.82 kg (4 lbs)
RegulatoryCE, FCC, UL
Warranty3-Year
Keyboard and MouseIncluded
