ExacqVision - IPS08-B13-OIA4 - Illustra Pro Gen4, 8MP Bullet, 3.6-11mm, TDN, w/IR, Indoor/Outdoor
Part number:
IPS08-B13-OIA4
Price:
Introducing the Pro Gen4 Bullet Camera, a cutting-edge solution offering exceptional vision powered by Illustra Pro AI. Boasting a robust smart mount with a unique arm design that minimizes cable installation time and costs, this camera ensures efficiency in any project. Installation is a breeze with quick in-camera configuration via app or HDMI, complemented by a focus assistant. Equipped with double-sensitive imagers, it excels in ultralow light environments, delivering improved image quality. Complete with full peripherals including EIS, dual alarm sets, and audio capabilities, it caters to a wide range of projects. Experience superior zoom capabilities with crystal-clear optics, adaptive Ex-IR illumination, and Illustra AI capturing details at long distances. Harness the power of edge AI with the industry’s most feature-rich Video AI suite, providing smart applications for round-the-clock surveillance operations.
Features:
- Robust Smart Arm for Easy Installation
- Extreme Weather Design with Full Preipherals
- Doubled Sensitivity for Better Clarity for Lowlight Conditions
- Comprehensive Cyber & Network Security
- Easy Installation
- Power Edge AI for Improved Security and Efficiency
- Ex-IR Illumination with Smart Power Designs
- 5-Year Warranty
| Camera Features | Pro Gen4 Bullet Camera |
| AI Object Classification | Person; Vehicle: Bicycle, bus, car, motorbike, train, truck; Retail: Cart; Suspicious objects: Backpack, handbag, suitcase; Sub-classes: Person clothing colors (upper, lower), vehicle colors; Rules: Object detected, abandoned/removed objects, direction, linger, dwell, enter, exit, crowd, queue, perimeter |
| Audio | Audio compression G.711 μ-law; Audio streaming Bi-directional, full duplex; Audio input/output 1x Line-in, 1x line-out, terminal block |
| Alarm Input/Output | 2x Line-in, 2x relay line-out (30V, 1A), terminal block- |
| B/W | 0.05 lux |
| Color | RAL 9003 signal white |
| Corridor Mode | Yes |
| Day/Night | True D/N by mechanically removable IR-cut filter, thresholds adjustable |
| Defog | Smart Defog |
| Digital Noise Reduction | Digital noise reduction 2D/3D |
| Dimensions | Standard lens: Ø79.9 x 205 mm (Ø3.2 x 8.1 in) Telephoto lens 2MP: Ø79.9 x 217 mm (Ø3.2 x 8.5 in) Telephoto lens 4/8MP: Ø79.9 x 235.5 mm (Ø3.2 x 9.3 in) |
| Environment Rating | NEMA 250 Type 4X, IEC/EN 62262 (IK10), IEC/EN 60529 (IP67/66) RoHS, WEEE, REACH |
| Ethernet | IEEE 802.3, 10/100 Base-T, 1x RJ45, auto sensing |
| Face Detection | AI Face detection |
| Gain Control | auto gain control |
| H.264 | Yes |
| H.265 | Yes |
| Image Stabilization | Electronic image stabilization (EIS) |
| IntelliZip | Yes |
| IR | 850 nm IR, power-efficient and durable Adaptive IR Smart IR Effective up to PoE 50 m (164 ft), PoE+ 70 m (230 ft) |
| Lens Type | Standard lens Motorized 4K optics, 3.6-11 mm, F1.5-2.8, P iris FOV (H): 102° ~ 47.8° FOV (V): 57.8° ~ 27.8° Telephoto lens Motorized 4K optics, 13-55 mm, F1.5-F2.8, P iris FOV (H): 34.2° ~ 8.3° FOV (V): 20° ~ 5.6° |
| Max Frame Rate | Up to 3840x2160 (16:9) at 30/25 fps, 1080p up to 60/50 fps |
| Motion Detection | Yes |
| Onboard Storage | 1x microSDXC slot, Class 10 or higher, up to 2TB capacity, card not incl 1~10 sec pre/post-event buffering Encrypted storage and streaming TrickleStor offline recording and backfilling via VideoEdge and ExacqVision NVR |
| Operating Temperature | -50 °C ~ 60 °C (-58 °F ~ 140 °F) |
| Power Draw | IR models: PoE 12.95 W, PoE+ 18.72 W, 24 VAC 21 W Non-IR models: PoE/PoE+ 9.55 W, 24 VAC 16 W |
| Power Input | Standard lens: PoE IEEE 802.3af Type 1 Class 4, PoE+ IEEE 802.3at Type 2 Class 4 Telephoto lens: PoE IEEE 802.3af, PoE+ IEEE 802.3at Type 2 Class 4 24 VAC, 1.27A (non-IR model 0.95A), terminal block |
| Resolution Options | Up to 3840x2160 (16:9) at 30/25 fps, 1080p up to 60/50 fps |
| Shutter Speed | 1/32,000 sec ~ 1/8 sec |
| Simultaneous Users | 10 |
| Supported Protocols | TCP/IP, IPv4, IPv6, TCP, UDP, HTTP, FTP, DHCP, WS-Discovery, DNS, DDNS, RTP, RTCP, RTSP, TLS, Unicast, Multicast, NTP, ICMP, IGMP, SMTP, WS-Security, IEEE 802.1x, PEAP, EAP-TLS, EAPoL, SSH, HTTPS, SOAP, WS-Addressing, CIFS, UPNP, LLDP, QoS, SIP |
| Vandal-Resistant | IK10 impact-resistant rated |
| Weight | Standard lens: Net 1.2 kg (2.7 lbs), gross 3.2 kg (7.1 lbs) Telephoto lens 2MP: Net 1.3 kg (2.9 lbs), gross 3.3 kg (7.3 lbs) Telephoto lens 4/8MP: Net 1.4 kg (3.1 lbs), gross 3.3 kg (7.3 lbs) |
| White Balance | auto white balance |
| Wide Dynamic Range | True WDR 120dB technologies Smart WDR, TWDR 2x, TWDR 3x Smart Defog |
