Ganz - ZNS-CVA-FIRE-1 - Fire and Smoke Detection CVA License (Cortrol Video Analytics)

Product Overview

Ganz ZNS-CVA-FIRE-1 is a one-channel server-side fire and smoke detection AI analytics license for the Ganz CORTROL Premier and CORTROL Global VMS platforms. It analyzes a compatible camera stream for visible flames and smoke, then generates events that can trigger automated alerts and emergency response workflows.

Key Configuration

Model: ZNS-CVA-FIRE-1 | License Type: Server-side fire and smoke analytics add-on | Coverage: 1 video channel | Platform: Ganz CORTROL Premier and Global | Analytics Engine: Deep learning neural network | Detection Classes: Flame and smoke | Processing: VMS server-side

Key Features

• · Adds visual fire and smoke detection to one camera stream within CORTROL VMS
• · Detects active flames and sparks using visual color, movement, and shape patterns
• · Tracks expanding grey, black, or white smoke plumes and their upward diffusion patterns
• · Analyzes the camera field of view for early visual indications of fire or smoke
• · Integrates with CORTROL Event and Action Manager for configurable emergency responses
• · Supports emergency layouts, PTZ positioning, snapshot emails, and HTTP API notifications
• · Uses deep-learning analysis to help distinguish fire and smoke from headlights, hazard lights, steam, and dust
• · Runs on the host VMS server and can use standard IP or analog cameras
• · Supports integration with building-management and other external response platforms through HTTP API actions
• · Suitable for visual monitoring of open or high-risk areas where early event notification is required

Technical Context

ZNS-CVA-FIRE-1 processes video on the CORTROL host server and evaluates visual patterns associated with flames and smoke rather than relying on physical particles or heat at a detector. Confirmed events are passed to CORTROL Event and Action Manager, where they can trigger operator layouts, PTZ actions, image notifications, HTTP API messages, or other configured emergency macros. Server-side processing allows the analytics to be used with compatible legacy IP or analog camera streams.

Installation Notes

This license is assigned to one camera stream within an existing Ganz CORTROL Premier or CORTROL Global installation and requires suitable server-side processing resources. Camera placement should provide a clear view of the monitored area. The ZNS-CVA-FIRE-1 is classified as discontinued as of 2026; existing licensed installations may continue operating within compatible CORTROL systems.
