Ganz - ZS1A-4DS - PixelPro GXi 4 Channel Network Encoder
Part number:
ZS1A-4DS
Price:
PixelPro GXi 4 Channel Network Encoder
Features:
- H.264 Full Frame at D1
- Video Compression: H.264, MPEG-4, MJPEG
- Deinterlacing on DSP
- Audio Compression: G.711
- Burnt-in Text, Video Motion Detection Support
- Comprehensive SDK Support
| MODEL | ZN-S110VE | ZS1A-1DS | ZS1A-4DS | ZN-S4000VEL | |
| Video | Input | 1 channel | 4 channel | ||
| Output | 1 Loop Out | - | 1 Loop Out | ||
| Compression Format | H.264, MPEG-4, MJPEG | H.264, MJPEG Selectable per Stream | Single Stream(H.264), Snapshot(MJPEG) | ||
| Number of Streams | Dual Stream, Configurable | 1 | |||
| Resolution | 720x480/576(D1),704x480/576(4CIF), 704x240/288(2CIF), 640x480(VGA), 352x240/288(CIF), 320x240(QVGA), 176x120/144(QCIF) | 720x480/576(D1), 704x480/576(4CIF), 640x480(VGA), 352x240/288(CIF), 320x240(QVGA),176x120/144(QCIF) | 720x480/576(D1),704x480/576(4CIF), 704x240/288(2CIF), 640x480(VGA), 352x240/288(CIF), 320x240(QVGA), 176x120/144(QCIF) | ||
| Frame Rate | 25/30fps @ D1 (PAL/NTSC) | ||||
| Deinterlacing | Supported | ||||
| Motion Detection | Supported | ||||
| Text Overlay | Supported | ||||
| Audio | Input | 1 channel | 4 channel | 2 channel | |
| Output | 1 channel | ||||
| Compression Format | G.711 | ||||
| Function | DI | 2 channel | 4 channel | ||
| DO | 2 channel | 4 channel | |||
| Serial Port | RS-485 Only | RS-232C, RS-485 | |||
| Network | 10 / 100 Base-T | 100 Base-T | |||
| Protocol | TCP/IP, UDP/IP, HTTP, RTSP, RTCP, RTP/UDP, RTP/TCP, SNTP, mDNS, UPnP, SMTP, IGMP, DHCP, FTP, DDNS, SSL v2/v3, IEEE 802.1X, SNMP v2/v3 | QoS Layer 3 DiffServ, TCP/IP, UDP/IP, HTTP, RTSP, RTCP, RTP/UDP, RTP/TCP, mDNS, UPnP™, SMTP, DHCP, DNS, DynDNS, NTP, SNMPv1/v2c/v3(MIB-II), IGMP, ICMP, SSLv2/v3, TLSv1 | TCP/IP, UDP/IP, HTTP, RTSP, RTCP, RTP/UDP, RTP/TCP, SNTP, mDNS, UPnP, SMTP, IGMP, DHCP, FTP, DDNS, SSL v2/v3, IEEE 802.1X, SNMP v2/v3 | ||
| USB 2.0 | - | ||||
| SD Memory Card Slot | - | Supported (64GB) | - | ||
| Electrical | Power Source | 12VDC (DC Jack) | 12VDC, PoE | 12VDC (DC Jack) | 12VDC, PoE |
| Power Over Ethernet | - | Supported (IEEE 802.3af) | - | Supported (IEEE 802.3af) | |
| Power Consumption (Approx) | 240 mA @ 12VDC | 235mA@12VDC | 735mA@12VDC | 550 mA @ 12VDC | |
| Environmental | Operating Temperature (Not include cold start) | -20 °C ~ 60 °C (-4 °F ~ 140 °F) | 0°C ~ 50°C | 12VDC: -10 °C ~ 50 °C (14 °F ~ 122 °F) PoE: -10 °C ~ 45 °C (14 °F ~ 113 °F) | |
| Operating Humidity | Up to 85% RH (Non-condensing) | ||||
| Mechanical | Dimensions | 103(W) x 38(H) x 141(D) mm / 4.1” x 1.5” x 5.6” | 137(W) x 38(H) x 243(D) mm | 137(W) x 38(H) x 189(D) mm / 5.4” x 1.5” x 7.4” | |
| Weight (Approx) | 385 g | 430 g | 920 g | 700 g | |
| Video Content Analysis (Included as Standard) | High Performance | Advanced Tracking Algorithm, Low False Alarm Rate | VCA Technology’s advanced tracking algorithm with rich library of detection behaviors | - | |
| Easy to Use | Intuitive Web Browser Interface | - | |||
| Detection Zones | Multi-segment Polygons and Lines | 40 zones (Multi-segment Polygons and Lines) in total 60 rules in total | - | ||
| On-screen Display | Real-time Display of Tracking Data and Events | - | |||
| Camera Shake Cancellation | Improve the VCA performance with cameras that are prone to shake | Supported | - | ||
| Tamper Detection | Detect camera tampering | Supported | - | ||
| Video Content Analysis (Option) | Detection Behavior | Direction, Stopping, Loitering, Entering, Exiting, Appear, and Disappear Filters, Abandoned/Removed Object Detection, Tailgating Detection | Enter, Exit, Appear, Disappear, Stop, Direction, Dwell filter; Tailgating; | - | |
| 3D Behavior | Perspective Corrected Size and Speed Filters | - | |||
| Statistics | Counting Functions and Other Statistics | - | |||
| Meta Data | Plain XML Format | - | |||
| Electronic Stabilization | Removes Camera Sway | - | |||
| Certifications | CE/FCC | ||||
| Onvif | - | Supported | - | ||
