GeoVision - 55-RG150-000 - Recording Server - GV 150 CH
• Up to 256 channels of recording and up to 600 channels of client distribution.
• Acts as a video gateway between IP devices and receiving clients .
• Supports third-party IP cameras and ONVIF, PSIA and RTSP protocols.
• Four recording modes: continuous, motion detection, I/O trigger and scheduled
• Bandwidth monitoring
• Two-way audio communication
• Alert status monitoring through GV-Vital Sign Monitor
• Complete backup solutions: GV-Backup Center, GV-Failover Server and GV-Redundant Server • Remote configuration and monitoring via any web browser
• Video playback using Remote ViewLog Passive and active connection methods with IP video devices (passive connection only supported by GV-IP devices).
• Mobile DVR solution (GV-Video Server and GV-Compact DVR) for obtaining a public IP address
• Supports 31 languages
| Number of IP Video Device Connections | 256 channels |
| Number of Remote Client Connections | 600 channels |
| Active Connections | Up to 256 channels |
| Passive Connections | Up to 128 channels (only for GV IP devices) |
| 3rd Party IP Cameras Support | Yes |
| Live Viewing | Single Live View, multi-channel live view |
| Recording | Yes (up to 256 channels) |
| Live Streaming on YouTube | Yes (up to 16 channels using H.264 codec) |
| Remote Backup | Yes (with GV-Backup Center, GV-Failover Server and GV-Redundant Server) |
| Protocol | DynDNS, HTTP, HTTPS, ONVIF, PSIA, RTSP, SMTP, TCP, UDP, UPnP |
| E-Mail Notification | Yes (for Active connection lost, passive connection lost, USB protection key removed and inserted, recycling of recorded video, start keep days operation, motion detection, disk full, disk error, I/O trigger, disk removed, recording failure) |
| SMS Notification | No |
| 2-Way Audio | Yes (only for GV-IP devices through active connection) |
| GPS support | Yes (only for GV-IP cameras) |
| Number of Accounts | Up to 1000 accounts |
| Mobile Phone Support | Yes (With GV-Eye) |
| Bandwidth Control | No |
| IE Live View | Yes (up to 16 channels per page) |
| IE Event Query | Yes |
| IE I/O Contro | No |
| Language | Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French / German / Greek / Hebrew / Hungarian / Indonesian / Italian /Japanese / Lithuanian / Norwegian / Persian / Polish / Portuguese / Romanian / Russian / Serbian / Simplified Chinese / Slovakian / Slovenian / Spanish / Swedish / Thai / Traditional Chinese / Turkish |
GV-Recording Server is a video streaming server for large-scale surveillance deployments. It has the ability to record up to 256 channels from various IP video sources. Each IP camera can be programmed to record video constantly, upon motion detection, upon I/O trigger or on a schedule, through its intuitive Web interfaces. It can also simultaneously distribute up to 600 channels to a variety of GeoVision software, including GV-VMS, GV-NVR, GV-Control Center, GV-Edge Recording Manager and others. The desired frame rates can be achieved while the CPU load and the bandwidth usage of IP video devices are greatly reduced when using GV-Recording Server. In addition, with GV-Backup Center, GV-Failover Server and GV-Redundant Server, GV-Recording Server offers a complete secure and affordable remote backup solution.
