Vivotek - SFP-1000-MM85-X5 - Gigabit Mini GBIC Multi Mode 850nm 0.5KM, LC Connector
Part number:
SFP-1000-MM85-X5
Price:
Gigabit Mini GBIC Multi Mode 850nm 0.5KM, LC Connector.
Features:
- Data Rate Gigabit 1.25G
- Type SFP
- Center Wave Length 850 nm
- Laser Type VCSEL
- Tx -3 ~ -10 dBm
- Rx -3 ~ -20 dBm
- Voltage 3.3V
- Transmission Range 50/125µm, 62.5/125µm, up to 0.5km
- Fiber Type (MMF/SMF) MMF
- Connector LC
- Dimensions (L x W x H) 55.9 x 14.69 x 12.39 mm
- Operating Temperature 0°C ~ 70°C (32°F ~ 158°F)
- Storage Temperature -40°C ~ 85°C (-40°F ~ 185°F)
- Humidity 5 ~ 90% (non-condensing)
- MSA Compliant Yes
- Certifications IEC 825, EN60825-1, FDA 21 CFR 1040.10 and 1040.11
| Model | SFP-1000-MM85-X5 |
| Data Rate | 1.25G |
| Wave Length | 850 nm |
| Laser Type | VCSEL |
| Tx(dBm) | -3 ~ -10 dBm |
| Rx(dBm) | -3 ~ -20 dBm |
| Voltage | 3.3V |
| Transmission Range | 50/125µm, 62.5/125µm, up to 0.5km |
| Fiber Type (MMF/SMF) | MMF |
| DDM (Digital Diagnostics Monitoring) | Yes |
| Connector | LC |
| Dimensions (L x W x H) | 55.9mm (L) x 14.69mm (W) x 12.39mm (H) |
| Operating Temperature | 0XC ~ 70XC (32XF ~ 158XF) |
| Storage Temperature | -40XC ~ 85XC (-40XF ~ 185XF) |
| Humidity | 5 ~ 90% (non-condensing) |
| MSA Compliant | Yes |
| Certifications | IEC 825, EN60825-1, FDA 21 CFR 1040.10 and 1040.11 |
Name
Description
Size
Downloads
File
Specification Sheet
0.4mb
File
Data Sheet
0.2mb
