TRENDNET - TFC-PGSFP - Gigabit PoE PD SFP Fiber Media Converter
Part number:
TFC-PGSFP
Price:

TRENDnet's Gigabit PoE PD SFP Fiber Media Converter, model TFC-PGSFP, converts 100/1000BASE-T copper Ethernet to 1000BASE-SX/LX Fiber SFP media and vice versa. The TFC-PGSFP is conveniently powered via PoE switch or injector, no power adapter is required. It features one gigabit PoE input port for power and data, plus one SFP slot that supports both multimode (SX) or single-mode (LX) SFP modules. The SFP slot accommodates both Fast Ethernet and Gigabit SFP modules providing further installation flexibility.



Features:

  • 1 x 100/1000BASE-T PoE input port
  • 1 x 100/1000BASE-SX/LX SFP slot
  • PoE Powered – no power adapter is required
  • SFP slot accommodates multimode or single-mode modules
  • Supports Link Fault Pass-Through (LFPT)
  • Jumbo Frame (9KB) Support
  • NDAA / TAA compliant (U.S. and Canada only)
Standards
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3ab
  • IEEE 802.3z
  • IEEE 802.3af
  • IEEE 802.3at
Device Interface
  • 1 x Gigabit PoE In port
  • 1 x 100/1000 Mbps SFP slot
  • LED indicators
Data Transfer Rate
  • Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)
  • Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)
  • Gigabit: 2000Mbps (full duplex)
Power
  • Powered by PoE+ Device
  • Max. consumption: 2.6W
PoE Delivery
  • Mode A and B
Operating Temperature
  • 0° – 50° C (32° – 122° F)
Operating Humidity
  • Max. 90% non-condensing
Dimensions
  • 102 x 75 x 23mm (4 x 2.95 x 0.9 in.)
Weight
  • 200g (7 oz.)
Certifications
  • CE
  • FCC
Warranty
  • 3-year warranty

PACKAGE CONTENTS

  • TFC-PGSFP
  • Quick Installation Guide
