• Max up to 8CH inputs
• AI functions
• Support BestShot Analytics events based on the AI engine
• Motion detection, Object detection, Virtual line (Crossing/Direction), Virtual area (Loitering/Intrusion/Enter/Exit)
• Analytics events - Virtual area (Appear/Disappear)
• Business Intelligence Based on an AI engine: People counting, Vehicle counting, Queue management, Heatmap
• Viewer Software: Web viewer, WAVE, Genetec, Milestone
• Support SDK/CGI(SUNAPI) for interworking with 3rd party VMS
| Display | |
|---|---|
| Network Inputs Max. | 8CH |
| Resolution | CIF ~ 32MP, Recommended Configuration: 8CH @ Full HD, 10fps |
| Protocols | [Certified Interoperability] - Hanwha non-AI network cameras (SUNAPI) - Hanwha Encoders (SUNAPI) [Limited] - 3rd party non-AI IP cameras (ONVIF/RTSP), compatibility is not 100% guaranteed. [Unsupported] - Any NVR/DVR - 3rd party Encoders |
| Intelligent Analysis | |
| AI function | Pre-Installed Event Classified object type : Person, Face, Vehicle, License plate, Attributes : Person (Upper/Lower clothes color, Gender, Bag), Vehicle (Type (car, bus, truck, motorcycle, bicycle), Color), Face (Age, Gender, Face mask, Glasses), Support Bestshot, Analytics events based on AI engine: Motion Detection*, Object detection, Virtual line* (Crossing/Direction), Virtual area* (Loitering/Intrusion/Enter/Exit), *Some of the video analytics only works with people/vehicle detection, Analytics events : Virtual area (Appear/Disappear), Business Intelligence (Based on AI engine) : People counting, Vehicle counting, Queue management, Heatmap, Dynamic privacy masking |
| Network | |
| Protocol | TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTSP, NTP, HTTP, DHCP (Server, Client), SMTP, ICMP, IGMP, ARP, DNS, DDNS, uPnP, HTTPS, SNMP, ONVIF (Profile-S), SUNAPI (Server, Client), SRTP, MQTT |
| DDNS | Hanwha DDNS |
| Max Manipulated Streams | 80 Streams (10 Streams per 1CH) |
| IP Version | IPv4/v6 |
| Security | IP address filtering, User access Log, 802.1x, Encryption, Device certificate (Hanwha Vision Root CA) |
| Language | English, French, German, Italian, Spanish, Russian, Turkish, Polish, Dutch, Czech, Portuguese, Hungarian, Greek, Korean, Chinese, Japanese |
| OS | Windows 11/10, macOS 10.13 |
| Web Browser | Google Chrome, Microsoft Edge, Mac Safari |
| Viewer Software Type | WebViewer, WAVE, SSM, Genetec, Milestone |
| CMS Support | Support SDK/CGI (SUNAPI) for interworking with 3rd party VMS |
| Functions | |
| Camera Setup | Register Auto, Manual |
| Setup Items | Camera Webpage |
| Indicator/Interface | |
| Front Indicator | LED (Status indicator) : Alarm(1), Power(1), Network(1) |
| Ethernet | RJ-45 1ea (1Gbps) |
| Alarm | (1) In (8EA, Terminal Block), (2) Alarm Reset (1EA), (3) Out (4EA, Terminal Block) - Relay Out1 (NO/NC/COM) - Relay Out2~4 (NO/COM) |
| USB | 1EA (Rear 1 x USB 3.0) for DEBUG |
| Serial | Not Supported (internal Debug) |
| Reset | Factory Reset |
| Power Cord | DIN 4P 12V, 4A |
| System | |
| Log | Log List Max. 3,000 (System 1,000, Access 1,000, EVENT 1,000) |
| CPU | NVIDIA ORIN NX 8GB (SOM) |
| Environmental | |
| Operating Temperature / Humidity | +0°C to +40°C (+32°F to +104°F) / 20% ~ 85% RH |
| Electrical | |
| Power | 100~240 VAC ±10%; 50/60Hz, 12V, 4A Adaptor |
| Power Consumption | 28W |
| Mechanical | |
| Color / Material | Black / Metal |
| Dimension (WxHxD) | 300 x 47.6 x 240.9mm (11.81 x 1.87 x 9.48inch) |
| Weight | 1.39kg |
