Hanwha - BRR-P1H1WH1-48TB - BLAZE Recording Server (Windows IoT OS)
- • 1U Rack-mount (4 x 3.5" HDD Bays).
- • Windows 11 IoT Enterprise LTSC 2024.
- • Supports up to 470 Mbps recording bandwidth.
- • Supports up to 80TB of raw storage (56TB usable after formatting and RAID 5).
- • Intel Xeon 6333P.
- • 16GB DDR5 (2x8GB) RAM.
- • NVIDIA T400 (GPU acceleration for AI search and 4K dewarping).
- • Dual 480GB SSDs (RAID 1) dedicated to the OS.
- • Hardware RAID Support: RAID 0, 1, 5, 6.
| System | |
|---|---|
| Product Name | 1U BLAZE Network Video Recorder |
| Pre-installed Software | BLAZE (pre-installed) |
| Raw Storage Capacity | Up to 80TB raw |
| Usable Capacity (after formatting & RAID 5) | 56TB usable |
| Recording Bandwidth | 470 Mbps recording B/W |
| HDD Bays (3.5") | 4 HDD Bay (3.5") |
| Processor | Intel Xeon 6333P |
| RAM | 16GB DDR5 (2x8GB) RAM |
| OS Drives | Dual 480GB SSD OS drives (RAID 1) |
| Operating System | Windows 11 IoT Enterprise LTSC 2024 |
| RAID Support | RAID 0/1/5/6 + 512MB NV cache |
| GPU | Nvidia T400 |
| Video Outputs | HDMI output, VGA output, 4x mDP |
| Network Interfaces | 2 x 1GbE NICs |
| Management | IPMI |
| Power Supplies | Redundant 450W power supplies |
| Keyboard & Mouse | Keyboard and mouse included |
| Rail Kit | Rail kit included |
| Storage & Performance | |
| Total Raw Capacity | Up to 80TB |
| Usable Capacity (RAID 5 + formatting) | 56TB |
| Recording Bandwidth | 470 Mbps |
| Number of HDD Bays | 4 bays (3.5") |
| OS Drive Configuration | Dual 480GB SSD (RAID 1) |
| RAID Levels Supported | RAID 0, 1, 5, 6 |
| Cache Acceleration | 512MB NV cache |
| Processor & Memory | |
| CPU | Intel Xeon 6333P |
| Memory Capacity | 16GB DDR5 (2x8GB) |
| Graphics & Display | |
| GPU Model | Nvidia T400 |
| Display Outputs | HDMI output, VGA output, 4x mDP |
| Network & Management | |
| Ethernet Interfaces | 2 x 1GbE NICs |
| Remote Management | IPMI (Intelligent Platform Management Interface) |
| Power & Mechanical | |
| Power Supply Configuration | Redundant 450W power supplies |
| Form Factor | 1U Rackmount |
| Included Accessories | Keyboard, mouse, rail kit |
| Chassis Type | Network Video Recorder (NVR) server chassis |
| Operating System & Software | |
| OS Platform | Windows 11 IoT Enterprise LTSC 2024 |
| VMS Software | BLAZE pre-installed |
| File System / RAID Management | RAID 0/1/5/6 with 512MB NV cache |
The Hanwha Vision BRR-P1H1WH1 is a 1U BLAZE Recording Server pre-configured with BLAZE VMS on a Windows 11 IoT Enterprise LTSC 2024 operating system, supporting up to 80TB raw storage with a recording bandwidth of 470 Mbps. It features 4 HDD bays, an Intel Xeon 6333P processor, 16GB of DDR5 RAM, and dual 480GB SSDs for the OS configured in RAID 1. The server supports RAID 0,1,5,6 with 512MB of NV cache, and includes an Nvidia T400 GPU with 4x Mini DisplayPort outputs, plus HDMI and VGA outputs. Network connectivity includes dual 1GbE NICs with IPMI for remote management. Redundant 450W power supplies provide reliability, and the server includes a keyboard, mouse, and rail kit. This compact 1U recording server is designed for space-constrained deployments requiring reliable performance and moderate storage capacity, running on the Windows 11 IoT Enterprise LTSC platform.
