Hanwha - BRR-P2H1SH7-480TB - BLAZE Recording Server (Windows Server OS)
- • 2U Rack-mount.
- • Windows Server 2022 (Standard).
- • Supports up to 1200 Mbps recording bandwidth.
- • Supports up to 360TB of raw storage.
- • Processor Intel Xeon.
- • Dual 480GB SSDs (RAID 1) for the OS.
- • Hardware RAID 0, 1, 5, 6, 10 for video data.
| System | |
|---|---|
| Product Name | 2U BLAZE Network Video Recorder |
| Pre-installed Software | BLAZE (pre-installed) |
| Raw Storage Capacity | Up to 480TB raw |
| Usable Capacity (after formatting & RAID 6) | 400TB usable |
| Recording Bandwidth | 1100 Mbps recording B/W |
| HDD Bays (3.5") | 28 HDD Bay (3.5") |
| Processor | Dual Intel Xeon Gold 5416S |
| RAM | 64GB RAM |
| OS Drives | Dual 480GB SSD OS drives (RAID 1) |
| Operating System | Windows Server 2022 Standard |
| RAID Support | RAID 0/1/5/6 + 8GB NV cache |
| GPU | Nvidia A400 GPU |
| Video Outputs | MiniDP output, VGA output |
| Network Interfaces | Dual 1GbE RJ45, Dual 10/25GbE SFP28 |
| Management | IPMI |
| Power Supplies | Redundant 1400W power supplies |
| Keyboard & Mouse | Keyboard and mouse included |
| Rail Kit | Rail kit included |
| Storage & Performance | |
| Total Raw Capacity | Up to 480TB |
| Usable Capacity (RAID 6 + formatting) | 400TB |
| Recording Bandwidth | 1100 Mbps |
| Number of HDD Bays | 28 bays (3.5") |
| OS Drive Configuration | Dual 480GB SSD (RAID 1) |
| RAID Levels Supported | RAID 0, 1, 5, 6 |
| Cache Acceleration | 8GB NV cache |
| Processor & Memory | |
| CPU | Dual Intel Xeon Gold 5416S |
| Memory Capacity | 64GB RAM |
| Memory Type | DDR4 / DDR5 (server-grade, configurable) |
| Graphics & Display | |
| GPU Model | Nvidia A400 GPU |
| Display Outputs | MiniDP output, VGA output |
| Network & Management | |
| Gigabit Ethernet | Dual 1GbE RJ45 |
| High-speed Networking | Dual 10/25GbE SFP28 |
| Remote Management | IPMI (Intelligent Platform Management Interface) |
| Power & Mechanical | |
| Power Supply Configuration | Redundant 1400W power supplies |
| Form Factor | 2U Rackmount |
| Included Accessories | Keyboard, mouse, rail kit |
| Chassis Type | Network Video Recorder (NVR) server chassis |
| Operating System & Software | |
| OS Platform | Windows Server 2022 Standard |
| VMS Software | BLAZE pre-installed |
| File System / RAID Management | RAID 0/1/5/6 with 8GB NV cache |
The Hanwha Vision BRR-P2H1SH7 is a 2U BLAZE Recording Server pre-configured with BLAZE VMS on a Windows Server 2022 Standard operating system, supporting up to 480TB raw storage with a recording bandwidth of 1100 Mbps. It features 28 HDD bays (3.5"), dual Intel Xeon Gold 5416S processors, 64GB of RAM, and dual 480GB SSDs for the OS configured in RAID 1. The server supports RAID 0, 1, 5, 6 with 8GB of NV cache, and includes an Nvidia A400 GPU with MiniDP and VGA outputs. Network connectivity includes dual 1 GbE RJ45 ports and dual 10/25 GbE SFP28 ports, with IPMI for remote management. Redundant 1400W power supplies provide reliability, and the server includes a keyboard, mouse, and rail kit. This high-performance recording server is designed for large-scale enterprise deployments requiring massive storage capacity and high bandwidth.
