Hanwha - BWT-P541W - BLAZE Workstation (Windows IoT OS)
Part number:
Price:
- • Form Factor: Small Form Factor (SFF).
- • Operating System: Windows 11 IoT Enterprise LTSC 2024.
- • Processor: Intel Core Ultra 5 (Engineered for efficient multi-stream 4K decoding).
- • Memory: 16GB RAM.
- • Storage: 512GB SSD (Dedicated OS/Application drive).
- • Graphics: Nvidia RTX A400 GPU.
- • 4 Mini-DisplayPort outputs.
- • 4 mDP to HDMI adapters included for immediate 4-monitor deployment.
- • Network: Dual NICs 1x 1GbE and 1x 2.5GbE for physical network separation.
- • Video Output (Integrated): 1 HDMI, 3 DisplayPort.
- • Included: BLAZE Client pre-installed; Keyboard and Mouse.
| System | |
|---|---|
| Video Management Software | BLAZE VMS |
| Licenses | No License |
| OS Drive Bays | SSD 512GB |
| Network Interface | 1 x RJ-45 (1Gbps), 1 x RJ-45 (2.5Gbps) |
| Processor | Intel Core Ultra 5 |
| Memory | 16GB DDR5 |
| Operating System | Windows 11 IoT Enterprise LTSC 2024 |
| Decoding Video Outputs | 1 x HDMI, 3 x DP, NVIDIA Quadro A400 4 x mDP, 4x mDP to HDMI adapter |
| USB Ports | Front: 2 x USB 2.0, 1 x USB 3.2 Gen2, 1 x USB 3.2 Gen 2x2 Type C Rear: 2 x USB 2.0, 3 x USB 3.2 Gen1, 1 x USB 3.2 Gen2 Type C |
| Audio Output | 1 x 3.5mm Universal Audio |
| Keyboard & Mouse | Keyboard, Mouse |
| Security | |
| Security Certificate | UL, cUL, CB, FCC, 80 Plus Platinum |
| Mechanical | |
| Form Factor | Tower |
| Color / Material | Black / Metal |
| Dimensions (WxHxD) | 3.74" (95 mm) x 11.95" (303.5 mm) x 11.53" (293 mm) |
| Weight | 13.47 lbs (6.11 kg) |
| Electrical | |
| Power Input | 100 ~ 240 VAC ±10%, 50/60 Hz |
| Power Supply | 360W 80 Plus Platinum |
| Environmental | |
| Operating Temperature | 41°F to 113°F (5°C to 45°C) |
| Storage Temperature | -40°F to 158°F (-40°C to 70°C) |
| Operating Humidity | 20% to 85% RH (non-condensing) |
| Calculation only | |
| OS_selection | Windows |
Name
Description
Size
Downloads
File
Datasheet
0.3mb
The Hanwha Vision BWT-P541W is a BLAZE Workstation pre-configured with BLAZE VMS on Windows 11 IoT Enterprise LTSC 2024. It features an Intel Core Ultra 5 processor, 16GB of DDR5 memory, a 512GB SSD, and dual network interfaces (1GbE and 2.5GbE). An NVIDIA Quadro A400 GPU 4x mDP with adapters, plus 1x HDMI and 3x DP outputs, provides flexible display connectivity. Housed in a tower chassis 3.74"x11.95"x11.53", 13.47 lbs, it operates at 5°C to 45°C and includes a keyboard and mouse. Power is supplied via a 360W 80 Plus Platinum power supply, 100-240VAC. Certifications include UL, cUL, CB, FCC, and 80 Plus Platinum.
