Hanwha - BWT-P721WM - BLAZE Workstation (Windows IoT OS)
Part number:
Price:
- • Micro Form Factor (Ultra-Compact).
- • Windows 11 IoT Enterprise LTSC 2024 (Hardened for 24/7 security stability).
- • Processor Intel Core Ultra 7.
- • Memory: 16GB RAM.
- • Storage: 512GB SSD (Dedicated OS/Application drive).
- • Network: 2.5 GbE NIC (High-bandwidth for multi-stream 4K viewing).
- • Video Output: (2) HDMI and (1) DisplayPort (Supports up to 2 concurrent monitors).
- • Included: BLAZE Client pre-installed; Keyboard and Mouse included.
| System | |
|---|---|
| Video Management Software | BLAZE VMS |
| Licenses | No License |
| OS Drive Bays | SSD 512GB |
| Network Interface | 1 x RJ-45 (1Gbps) |
| Processor | Intel Core Ultra 7 |
| Memory | 16GB DDR5 |
| Operating System | Windows 11 IoT Enterprise LTSC 2024 |
| Decoding Video Outputs | 2 x HDMI, 1 x DP |
| USB Ports | Front: 1 x USB 3.2 Gen 1, 1 x USB 3.2 Gen2 Type C Rear: 2 x USB 2.0, 2 x USB 3.2 Gen1 |
| Audio Output | 1 x 3.5mm Universal Audio |
| Keyboard & Mouse | Keyboard, Mouse |
| Security | |
| Security Certificate | UL, cUL, CB, FCC |
| Mechanical | |
| Form Factor | Micro Form Factor |
| Color / Material | Black / Metal |
| Dimensions (WxHxD) | 1.42" (36 mm) x 7.17" (182 mm) x 7.01" (178 mm) |
| Weight | 3.09 lbs (1.40 kg) |
| Electrical | |
| Power Input | 100 ~ 240 VAC ±10%, 50/60 Hz |
| Power Supply | 90W adapter 4.5mm barrel |
| Environmental | |
| Operating Temperature | 50°F to 95°F (10°C to 35°C) |
| Storage Temperature | -40°F to 149°F (-40°C to 65°C) |
| Operating Humidity | 20% to 80% RH (non-condensing) |
| Calculation only | |
| OS_selection | Windows |
Name
Description
Size
Downloads
File
Datasheet
0.3mb
The Hanwha Vision BWT-P721WM is a BLAZE Workstation pre-configured with BLAZE VMS on Windows 11 IoT Enterprise LTSC 2024. It features an Intel Core Ultra 7 processor, 16GB of DDR5 memory, a 512GB SSD, and a 1GbE network port. Video outputs include 2x HDMI and 1x DisplayPort. Housed in a compact micro form factor 1.42" x 7.17" x 7.01", 3.09 lbs, it operates at 10°C to 35°C and includes a keyboard and mouse. Power is supplied via a 90W adapter, 100-240VAC. Certifications include UL, cUL, CB, and FCC.
