Hanwha - CGR-1610-32TB - OnCloud Gateway Appliance, 32TB
• Supports up to 16ch, 150Mbps recording
• Supports up to 2x3.5” HDD, up to 16TB per SATA, Total 32TB HDD capacity
• Two Gigabit network ports(10/100/1000 BASE-T)
• NDAA compliant, FCC Certified
• The Cloud Gateway Recorder is a device for local recording and connecting to Hanwha OnCloud for third-party cameras or Hanwha IP cameras that do not have the Cloud Connector app.
| Performance & Storage | |
| Operating System | Embedded Linux |
| Recording Bandwidth | Max. 150Mbps |
| Storage Supported HDD | Up to 16TB |
| HDD Slot | SATA 2ea (Max. 32TB) |
| Interface | |
| Front Indicator | Power, Network, HDD |
| HDMI | 1EA (Reserved) |
| DP | 1EA (Reserved) |
| Audio | Audio output (Reserved) |
| Ethernet | RJ-45 2ea (10/100/1000 BASE-T) |
| USB | Front USB 2.0 (2), Rear USB 3.0 (2) |
| Environmental | |
| CPU | Dual core |
| RAM | DDR4 8GB |
| OS HDD | eMMC 32GB |
| Operating Temperature | 0°C to +40°C (32°F to 104°F) |
| Operating Humidity | 20% ~ 85% RH |
| Electrical | |
| Power Input | 100 ~ 240 VAC ±10%; 50/60 Hz |
| Power Consumption | 64W |
| Mechanical | |
| Color / Material | Black / Metal |
| Dimension (WxHxD) | 370 x 51 x 324mm (14.6 x 2 x 12.8") |
| Weight | 2.7Kg (5.95lb) |
The Hanwha Vision CGR-1610 is an OnCloud gateway appliance powered by an embedded Linux operating system, featuring a dual-core CPU, 8GB of DDR4 RAM, and 32GB of eMMC flash storage. It delivers a maximum recording bandwidth of 150Mbps and supports up to 2 SATA HDD slots with a total storage capacity of 32TB. The appliance includes dual Gigabit Ethernet ports, front USB 2.0 ports, and rear USB 3.0 ports. It also features reserved HDMI and DisplayPort outputs, as well as a reserved audio output. The CGR-1610 operates from 0°C to +40°C with 20% to 85% RH humidity. Power input is 100-240VAC at 50/60Hz with a maximum power consumption of 64W. Front panel indicators include Power, Network, and HDD status LEDs. This gateway appliance is designed for cloud-based video surveillance deployments requiring moderate bandwidth and scalable storage capacity.
