Hanwha - EN-BR324p-0 - Wisenet SKY CMVR 324+
Part number:
EN-BR324p-0
Price:
Wisenet SKY CMVR 324+ with 4TB (Compact and Ruggedized Form Factor)
Features:
- Supports up to 44 @ 1MP cameras ~ 35 @ 4MP cameras*
- Supports up to 15 cloud analytics, with supported license
- Intelligent Bandwidth Management with local buffering records up to 2 days
- Dual gigabit network ports
- Fully cloud managed
- Supports motion or continuous recording
- Supports Wisenet and ONVIF conformant IP cameras
- Complete encryption of video in transit and at rest
- Ruggedized chassis for extended temperature range, solid state disk, fanless design
- LCD display for connectivity and operational status
| SYSTEM | ||
| Maximum Cameras @ 1MP | 25 / 44 | |
| Maximum Cameras @ 4MP | 20 / 35 | |
| Maximum Cloud Analytics | 5 / 15 | |
| Hard Disk Drive | 1TB, 800Gb usable for video storage, Solid State Drive | |
| Network ports | Dual gigabit ethernet RJ-45 | |
| PoE Ports | NA | |
| Indicators | Power, Disk Activity, Temperature, IP Address & Speed, Serial number, Attach ID | |
| Video output | 1x HDMI, 1x VGA | |
| USB ports | 4x USB 3.0 / 4x USB 3.0, 2x USB 2.0 | |
| Operating System | Embedded Linux | |
| Included accessories | Wall mount, power supply | |
| Rack Mount Brackets | NA | |
| Ordering SKU | EN-SU304P-0 / EN-SU404P-0 | |
| MECHANICAL / ELECTRICAL / ENVIRONMENTAL | ||
| Mechanical | Form Factor | Compact wall or shelf mount |
| Color / Material | Blue, Aluminum | |
| Dimensions | 180 x 127 x 64 mm 7.08 x 5.00 x 2.50 in | |
| Weight | 2.25Lb (1.2kg) / 2.72Lb (1.23kg) | |
| Electrical | Power Supply | Included, 20 W / 30 W |
| Power Input | 100 ~ 240V AC | |
| Environmental | Operating Temperature | 14°F to 122°F (-10°C to 50°C) |
| Operating Humidity | 0% to 70% RH, non-condensing | |
| Certification | FCC, UL, CE, UKCA, PSE, NOM, ACM, RoHS, CTick, WEEE, NDAA | |
