Video

Inputs

8CH BNC, : AHD (4MP), TVI (2MP), CVI (2MP), NTSC / PAL

Resolution

x 1440, 1920 x 1080, 1280 x 720, 960 x 480, 704 x 480,

x 576, 704 x 576

Live

Frame Rate

240fps, 200fps

Resolution

x 1440, 1920 x 1080, 1280 x 720, 960 x 480, 704 x 480,

x 576, 704 x 576

Multi Screen Display

/ 4 / 7 / 9 / PIP / Sequence

Operating System

Embedded

Linux

Recording

Compression

H.264

Record Rate

NTSC : Up to 120fps@4MP / PAL : Up to 100fps@4MP

NTSC : Up to 240fps@1920 x 1080 / PAL : Up to 200fps@1920 x 1080

NTSC : Up to 240fps@1280 x 720, 928 x 480, 704 x 480, 704 x 240, 352 x 240

PAL : Up to 200fps@1280 x 720, 928 x 576, 704 x 576, 704 x 288, 352 x 288

Mode

Manual, Schedule (Continuous / Event), Event (Pre / Post), Time lapse (1 ~ 30fps(N), 1 ~ 25fps(P))

Event

Video Loss, Motion (Level 1 ~ 10), Alarm Input (16), Tampering (Level Low, Medium, High)

Overwrite Modes

Continuous

Pre-alarm

Up to 30 sec (5, 10, 20, 30 sec)

Post-alarm

Up to 6 hour (5, 10, 20, 30 sec,1, 3, 5, 10, 20 Min,1, 2, 3, 4, 5, 6 hour)

Search & Playback

Search Mode

Date / Time, Event, Back up, POS (SD Signal only), Motion (※ All Search Included Preview Function)

Playback Function

Fast forward / backward (2x, 4x, 8x, 16x, 32x, 64x) *Backward play with i-frame only

Slow forward / backward (1/2x, 1/4x, 1/8x)

Step Forward / backward ※ Backward play with I-frame only

Network (IPv4)

Transmission Speed

Record Stream : 4M : 15fps, 1080p / 720p / WD1 / 4CIF / CIF (NTSC : 30fps, PAL : 25fps) Network Stream : WD1 / 4CIF : 12fps, 2CIF / CIF (NTSC : 30fps, PAL : 25fps)

Bandwidth

Up to 64Mbps

Bandwidth Control

Selectable

Stream

Record stream and network stream selectable (at monitoring viewer)

Max. Remote Users

Search 3 / Live unicast 10 / Live multicast 20

Protocol Support

TCP/IP, DHCP, PPPoE, SMTP, NTP, HTTP, DDNS, RTP, RTSP, SNMP

Monitoring

SSM, WebViewer, SmartViewer, iPOLiS Mobile Viewer

Smart Phone

Platform

Android, iOS

Protocol Support

RTP, RTSP, HTTP

Control

Live (8CH) : Multi-profile support playback (1CH)

Max. Remote Users

Search 3 / Live unicast 10 / multicast 20

Storage

Internal HDD

Up to 4 SATA HDDs (0 ~ 8TB HDDs)

External (e-SATA Interface)

e-SATA, USB (for Backup)

File Format (Backup)

BU (DVR player), SEC (Include player), AVI

Security

Password Protection

Admin, 10 Group, 10 User per 1 Group

Data Authentication

Watermark

Monitors

VGA

VGA (1920 x 1080, 1280 x 1024, 1280 x 720)

HDMI

HDMI (4K (3840 x 2160), 2K (2560 x 1440), 1920 x 1080, 1280 x 1024, 1280 x 720)

Spot Composite

BNC (1CH) ※ Included OSD on screen, Multi mode support

Audio

Inputs / Output

8CH line in (Built-in 4CH, Option : Audio extension cable) / 1CH line out

Compression

G.711

Sampling Rate

8KHz

Alarm

Inputs / Output

Terminal 8 inputs (NO/NC) / Terminal 4 Relay outputs (NO/NC), Rating : 30V DC / 2A, 250V AC / 0.25A

Remote Notification

Notification Via E-mail

Connections

Ethernet

RJ45 10/100/1000 Base-T

Serial Interface

RS-485 (Full duplex) for PTZ, Samsung system keyboard

USB

port (USB 3.0, Rear), 1 port (USB 2.0, Front)

e-SATA

External SATA ports

Application Support

Mouse, IR Remocon

RS-485 Protocol

Samsung-T/E, Pelco-D/P, Panasonic, Phillips, AD,

DIAMOND, ERNA, KALATEL, VCL TP, VICON, ELMO, GE

Coax Protocol

NTSC/PAL : Pelco-C (Coaxitron), AHD : ACP (AHD Coax Protocol)

Electrical

Input Voltage / Current

~ 240V AC ±10%, 50/60 Hz

Power Consumption

Max. 25W (1 x 2T HDD)

Environmental

Operating Temperature

+0°C ~ +40°C (+32°F ~ +104°F)

Operating Humidity

20% ~ 85% RH

Mechanical

Dimensions (WxHxD)

x 88.0 x 384.8mm (17.32” x 3.46” x 15.15”)

Weight (With hard disks)

Approx. 5.24Kg (11.55 lb)

LAUGUAGE

GUI

English, French, German, Spanish, Italian, Russian, Polish, Czech,

Turkish, Netherlands, Portuguese, Swedish, Danish, Rumania, Serbia,

Croatia, Hungary, Greek, Finnish, Norwegian, Korean, Japanese, Chinese (Traditional), Thai
