Hanwha - HV-IE340-12GP-980 - 8 x Gigabit Ethernet PoE+ Total 240W (8/ 8 PoE at/af)
Part number:
Price:
The Hanwha HV-IE340-12GP-980 is a high-performance, industrial-grade Layer 3 managed switch (Allied Telesis IE340 series equivalent). It is specifically designed to provide robust network infrastructure for mission-critical surveillance, such as Hanwha AI cameras, in harsh environments like utility substations, manufacturing floors, and outdoor enclosures.
| Network Switch Specifications | |
|---|---|
| 10/100/1000T Copper Ports | 8 |
| 100/1000X SFP Ports | 4 |
| Total Ports | 12 |
| PoE Enabled Ports | 8 |
| Switching Fabric | 24 Gbps |
| Forwarding Rate | 17.8 Mpps |
| Input Voltage | 18~57V DC |
| Non PoE+ Load | |
| Max Power Consumption (W) | 24 |
| Max Heat Dissipation (BTU/H) | 81.9 |
| Max Noise (dBA) | Fanless |
| Full PoE+ Load | |
| Max Power Consumption (W) | 271 |
| Max Heat Dissipation (BTU/H) | 105.8 |
| Max Noise (dBA) | Fanless |
| Total PoE Power Budget (W) | 240 |
| PoE Sourcing Ports | PoE (15W): 8, PoE+ (30W): 8, PoE++: - |
| Physical Characteristics | |
| Width / Depth / Height | 91 x 139 x 153 mm (3.58 x 5.47 x 6.02 in) |
| Weight | Din rail: 2.34 kg (5.16 lb), Wall mount: 2.23 kg (4.91 lb) |
| Enclosure | Aluminium, Sheet Metal Shell |
| Protection Rate | IP30 |
| Port Speed Latency | 100 Mbps: 5.46 µs, 1 Gbps: 2.44 µs |
