Hanwha - HV-IE340-20GP-980 - 16 x Gigabit Ethernet PoE+ Total 240W (16 PoE at/af)
Part number:
Price:
• Designed for industrial environment 1
• Standard northbound interface for network automation NETCONF/RESTCONF and network orchestration OpenFlow
• Industrial automation and control protocols
• PROFINET, Modbus/TCP
• Network time synchronization 2
• Comprehensive low-latency wire-speed QoS for video streaming
• Dual power inputs for redundancy
• DIN rail and wall mount
• Air convection cooling (fanless)
• Extended operating temperature range: -40°C to 75°C (-40°F to 167°F); tested @ 85°C
| Network Switch Specifications | |
|---|---|
| 10/100/1000T Copper Ports | 16 |
| 100/1000X SFP Ports | 4 |
| Total Ports | 20 |
| PoE Enabled Ports | 16 |
| Switching Fabric | 40 Gbps |
| Forwarding Rate | 29.7 Mpps |
| Input Voltage | 18~57V DC |
| Non PoE+ Load | |
| Max Power Consumption (W) | 24 |
| Max Heat Dissipation (BTU/H) | 81.9 |
| Max Noise (dBA) | Fanless |
| Full PoE+ Load | |
| Max Power Consumption (W) | 271 |
| Max Heat Dissipation (BTU/H) | 105.8 |
| Max Noise (dBA) | Fanless |
| Total PoE Power Budget (W) | 240 |
| PoE Sourcing Ports | PoE (15W): 16, PoE+ (30W): 8 |
| Physical Characteristics | |
| Width / Depth / Height | 91 x 139 x 153 mm (3.58 x 5.47 x 6.02 in) |
| Weight | Din rail: 2.34 kg (5.16 lb), Wall mount: 2.23 kg (4.91 lb) |
| Enclosure | Aluminium, Sheet Metal Shell |
| Protection Rate | IP30 |
| Port Speed Latency | 100 Mbps: 5.38 µs, 1 Gbps: 2.43 µs |
