Hanwha - HV-X530L-10GHXM-90 - 8 x Gigabit Ethernet PoE++ 500W
Part number:
Price:
• 8/16/24/48 ports, with 2/4 uplinks
• 520/740W PoE+/PoE++ power budget
• Fully managed
• AW+ OS (CLI, GUI and NetCONF/RESTCONF)
• SFP+ support 1Gbps and 10Gbps
• Active fiber monitoring
• Static and multicast routing
• Tri-authentication: MAC-based, Web-based and IEEE 802.1x
• QoS classification
• Virtual Chassis Stack (up to 8)
• EPSR Master or Transit
| Network Switch Specifications | ||
|---|---|---|
| 10/100/1000T Copper Ports | 8 | |
| 100M/1/2.5/5 Gigabit Ports | 8 | |
| 1/10G SFP+ Ports | 2 | |
| Total Ports | 10 | |
| PoE+ Enabled Ports | 8 | |
| Switching Fabric | 120 Gbps | |
| Forwarding Rate | 89.2 Mpps | |
| Non PoE+ Load | ||
| Max Power Consumption (W) | 60 | |
| Max Heat Dissipation (BTU/H) | 204 | |
| Max Noise (dBA) | 64 | |
| Full PoE+ Load | ||
| Max Power Consumption (W) | 605 | |
| Max Heat Dissipation (BTU/H) | 2065 | |
| Max Noise (dBA) | 64 | |
| Total PoE Power Budget (W) | 500 | |
| PoE Sourcing Ports | PoE (7.5W): 8, PoE (15.4W): 8, PoE+ (30W): 8, PoE++ (60W): 8, PoE++ (90W): 5 | |
| Physical Characteristics | ||
| Height | 42.5 mm (1.67 in) | |
| Width | 210 mm (8.27 in) | |
| Depth | 362 mm (14.25 in) | |
| Weight | 3.5 kg (7.72 lb) | |
| Port Speed Latency | ||
| 100 Mbps | 8.24 µs | |
| 1 Gbps | 7.89 µs | |
| 2.5 Gbps | 5.63 µs | |
| 5 Gbps | 3.49 µs | |
| 10 Gbps | 2.12 µs | |
