Hanwha - PNO-A9081RLP - 4K IR Bullet AI Camera with Wisenet Road

Product Overview

The PNO-A9081RLP is a 4K IR bullet AI camera featuring pre-installed Wisenet Road AI optimized for low-to-moderate speed license plate recognition. It carries ultra-rugged IP66/IP67/IP6K9K, IK10+, and NEMA4X environmental ratings and utilizes a 1/1.8" CMOS sensor with a 4.5~10mm motorized varifocal lens to deliver 4K (3840×2160) resolution at 30 fps, supported by a 30m (98 ft) IR range.

Key Configuration

• • Imaging device: 1/1.8" CMOS; resolution: up to 3840×2160 (4K) at 30 fps
• • Lens: 4.5~10mm (2.2x) motorized varifocal; lens mount: C-mount, CS-mount
• • IR viewable length: 30m (98.42 ft); minimum illumination: color 0.03 lux (F1.2, 1/30 sec), B/W 0.003 lux, 0 lux with IR
• • Video compression: H.265, H.264, MJPEG; WiseStreamⅡ, WiseStreamⅢ (AI-based)
• • Power: PoE+; power consumption not specified

Key Features

Key features include a pre-installed Wisenet Road AI application providing edge-based LPR, make/model, and daytime color recognition, supporting Smart Search filtering and Allow/Deny list notifications alongside a 32GB microSD card that stores 10,000 traffic images. Performance is optimized via 120dB WDR, gyro-based Digital Image Stabilization (DIS), and WiseStreamⅢ bandwidth reduction. For physical deployment and integration, the unit includes flexible audio detection (line/mic inputs), 1 alarm input/output, and dual installation video outputs via CVBS and micro-USB.

Technical Context

Supports DC auto iris, P-iris, and manual lens types with simple focus control and SSNRⅤ digital noise reduction. It features flexible video adjustment (flip, mirror, 90°/270° hallway view), 8 polygonal motion detection zones, 6 rectangular privacy masks, and an electronic shutter speed ranging from 1/5 to 1/12,000 sec. Edge intelligence includes built-in analytics for defocus, motion, tampering, audio detection, sound classification, and shock detection, all running on a licensed open-platform application optimized for multiple global regions.

Installation Notes

Engineered with IP66/IP67/IP6K9K, IK10+, and NEMA4X protection ratings, this durable housing supports flexible optics via C-mount or CS-mount lens compatibility. Installation is streamlined by dual setup video outputs (CVBS BNC and micro-USB), while integrations are supported by a micro-SD slot for storage expansion, selectable audio inputs (mic/line/built-in), and 1 alarm input/output that provides auxiliary 12VDC power (max 50mA) for external devices.
