Hanwha - SKY-BR325-0 - Wisenet SKY CMVR
Part number:
SKY-BR325-0
Price:

The Wisenet SKY Cloud Managed Video Recorder (CMVR) stores video and acts as a gateway from your premises to the Wisenet SKY Cloud Data Center where your video can also be stored and managed by the Wisenet SKY Cloud VMS. It provides secure video storage & video streaming, intelligent bandwidth management, and monitoring of cameras.



These small form factor CMVRs are designed for applications of up to 12 cameras when a server rack is not available. They are suitable for wall or shelf mounting. Onpremises recording can be combined with cloud recording for additional redundancy, with an available subscription.



Features:

  • CMVR 325 with 2TB (Compact and Ruggedized Form Factor with 4 PoE Ports)
  • 1MP: 12CH, 4MP: 8CH, Analytics: 5CH, 2TB HDD (45 days for 8 cameras @ 1MP), HDMI, DP, 4PoE ports
  • This product is subject to the Wisenet SKY agreement.Supports up to 12 @ 1MP cameras ~ 8 @ 4MP cameras*
  • Supports up to 5 cloud analytics, with supported license
  • Intelligent Bandwidth Management with local recording up to 10 days (12 cameras @ 1MP)
  • Dual gigabit network ports
  • Fully cloud managed • Supports motion or continuous recording
  • Supports Wisenet and ONVIF conformant IP cameras
  • Complete encryption of video in transit and at rest
  • HDMI & DisplayPort video outputs for local display
  • Compact form factor for wall or shelf mounting
  • Front panel indicator lights



STANDARD SUPPORT (Included)

  • Free of charge with an active subscription
  • No cost replacement with an active subscription
  • 24/7 email and web support
  • Standard phone support
SYSTEM
Maximum Cameras @ 1MP12 / 12
Maximum Cameras @ 4MP8 / 8
Maximum Cloud Analytics5
Hard Disk Drive2TB / 2TB
2TB 10 days for 12 cameras @ 1MP
Network portsDual gigabit ethernet RJ-45 / Single gigabit ethernet
PoE Ports0 / 4 PoE ports of IEEE802.3af class 3 (325 only)
Video output1x HDMI, 1x DisplayPort
USB ports2x USB 3.0
Operating SystemEmbedded Linux
Included accessoriesWall mount, power supply
Ordering SKUEN-BR324-0 / EN-BR325-0
MECHANICAL / ELECTRICAL / ENVIRONMENTAL
MechanicalForm FactorCompact wall or shelf mount
Color / Material324: Black / Plastic, 325 Black / Metal
Dimensions5.00" x 5.01" x 1.75" (125mm x 127mm x 47mm) 324
5.00" x 6.77" x 2.95" (127mm x 172mm x 75mm) 325
 Weight1.4lb (0.64kg) 324 / 4.24lb (1.92kg) 325
ElectricalPower SupplyIncluded, 20 W / 22 W
Power Input100 ~ 240V AC
EnvironmentalOperating Temperature32°F to 95°F (0°C to 35°C)
Operating Humidity0% to 70% RH, non-condensing
CertificationFCC, UL, PSE, CE, CCC(S&E), REACH, RoHS, C-Tick, NDAA
