The Wisenet SKY Bridge acts as a gateway from your premises to the Cloud Data Center where your video is stored and managed. The bridge provides video buffering, a secure connection, bandwidth management, and monitoring of cameras. These 1U rack-based bridges are designed to fit in a standard equipment rack. The rack mount bridges are offered to support larger number of cameras
Features:
STANDARD SUPPORT (Included)
| MODEL | Bridge 301 | Bridge 401 | Bridge 501 |
| Maximum Cameras (1MP)* | 15 IP | 30 IP | 50 IP |
| Maximum Cameras (4MP)* | 12 IP | 25 IP | 35 IP |
| Maximum Analytic Count* | 5 | 10 | 10 |
| Video Buffer | 2 days on-premise | ||
| Hard Drives | Spinning hard disk drives | ||
| POE Camera Ports | None | ||
| Network Ports | Dual Gigabit | ||
| Video Output | 1x VGA, 1x DVI | 1x VGA, 1x HDMI, 1x DisplayPort | |
| Dimension | 427mm x 251mm x 45mm 16.81" x 9.88" x 1.75", 1U | ||
| Included power supply | Internal 100-240 VAC, 65 W | Internal 100-240 VAC, 50 W | |
| Operating Temperature Range | 0°C to 35°C 32°F to 95°F | ||
| Operating Humidity Range | 0 to 70% | ||
| Certifications | FCC, UL, PSE, CE, CCC(S&E), REACH, RoHS, C-Tick, NDAA | ||
