Hanwha - SKY-SW10g-001 - Network Switch SW10g
Part number:
SKY-SW10g-001
Price:

Wisenet SKY Switch SW10g (8 Port Gigabit POE+, 2 GSFP uplink ports) & power cycle capability when used with Wisenet SKY Cloud VMS. The Wisenet SKY PoE switches are industry standard highly reliable PoE switches designed to seamlessly integrate with the Wisenet SKY VMS. Gigabit switches are great for display stations that require higher bandwidth, if network topology requires cascading multiple switches, for locations where multiple bridges are deployed, or for flexible mounting options.

Total Number of Ports10
PoE Ports8 PoE+
Uplink Ports2 SFP
Power SupplyBuilt-in Power Supply
Voltage RangeAC100-240V
PoE Specifications

54 VDC

802.3af (max 15.4W), 802.3at (max 30W)

Maximum Power Budget125W
Speed10/100/1000 Mbps
Dimension (L x W x H)270 x 180 x 44mm 10.6 x 7.1 x 1.7in
Switching Capacity20 Gbps
MAC Address8K MAC address table
Temperature Range0-50° C (32-122°F)
Storage Temperature-20-70° C (-4-158°F)
Rack MountableRack or wall mounting (Brackets included)
Name
Description
Size
Downloads
File
A&E Specifications
0.8mb
File
Datasheet
0.3mb
