Hanwha - SKY-SW28g-001 - Wisenet SKY Cloud VMS 26 Port PoE+ Network Switch
Part number:
SKY-SW28g-001
Price:

Wisenet SKY Switch SW28g (26 Port POE+, Gigabit, with 2x SFP gigabit uplinks), & power cycle capability when used with Wisenet SKY Cloud VMS. The Wisenet SKY PoE switches are industry standard highly reliable PoE switches designed to seamlessly integrate with the Wisenet SKY VMS. Gigabit switches are great for display stations that require higher bandwidth, if network topology requires cascading multiple switches, for locations where multiple bridges are deployed, or for flexible mounting options.

Total Number of Ports28
PoE Ports24 PoE+
Uplink Ports2 RJ-45 and 2 SFP
Power SupplyBuilt-in Power Supply
Voltage RangeAC100-240V
PoE Specifications

54 VDC

802.3af (max 15.4W), 802.3at (max 30W)

Maximum Power Budget370W
Speed10/100/1000 Mbps
Dimension (L x W x H)440 x 200 x 44mm 17.3 x 7.9 x 1.7in
Switching Capacity56 Gbps
MAC Address8K MAC address table
Temperature Range0-50° C (32-122°F)
Storage Temperature-20-70° C (-4-158°F)
Rack MountableRack or wall mounting (Brackets included)
Name
Description
Size
Downloads
File
Hanwha Techwin America - NDAA Compliant Product List
0.4mb
File
A&E Specifications
0.8mb
File
Datasheet
0.3mb
