Hanwha - SLA-5M4600D - PNM-9000VD Lens module
Part number:
SLA-5M4600D
Price:
1/1.8" 5MP CMOS with a 4.6mm fixed focal lens, FoV: H: 77.9˚, V: 57.9˚ for the PNM-9000VD
Features:
- 0.16Lux@F1.6 Color, B/W (5MP lenses)
- Selectable lens options: 3.7 / 4.6 / 7.0mm fixed lens (5MP)
VIDEO
| Imaging Device | 1/1.8" 5MP CMOS |
| Effective Pixels | 2616(H) x 1976(V) |
| Minimum Illumination | Color : 0.16Lux (F1.6, 1/30sec, 30IRE) B/W : 0.16Lux (F1.6, 1/30sec, 30IRE) |
LENS
| Focal Length | 4.6mm fixed focal |
| Maximum Aperture Ratio | F1.6 |
| Angular Field of View | H : 77.9˚, V : 57.9˚, D : 98.7˚ |
| Lens Type | Fixed focal |
PAN / TILT / ROTATE
OPERATIONAL
| Wide Dynamic Range | 120dB |
| Day & Night | Auto (Electrical) |
MECHANICAL
Color / Material
| Product dimensions / weight | Ø35.5 x 35.9mm (1.40 x 1.41") / 35g (0.08 lb) |
Name
Description
Size
Downloads
File
Datasheet
1mb
File
NDAA Compliant
0.4mb
