Hanwha - WRN-1610S-24TB - Wisenet Wave Wrn 1610s 16 Channel Wave Poe+ NVR With 24TB HDD Linux
Part number:
WRN-1610S-24TB
Price:
2U WAVE PoE NVR (Intel based) with 4 Professional licenses, 24TB RAW, supports: 16 channels with 16 PoE/PoE+ ports (PoE Budget 200W), Wisenet WAVE pre-installed, H.264/H.265/MJPEG, 4 fixed internal SATA HDDs (6TB max per HDD), Wisestream technology, HDMI/VGA output, Dual GbE NICs
Features:
- Up to 16 PoE+ channels
- Includes 4 WAVE Pro Licenses
- Supports H.265/H.264/MJPEG cameras
- Max 4 HDDs
- HDMI/VGA monitor outputs for configuration and basic monitoring
- 16 PoE/PoE+ ports, with a total power budget of 200W
- PoE port control & Alarm I/O supported
- ONVIF camera compliant
- Rack mountable
- Supports up to 24Tb of internal storage with 4 HDDs
- Recommended maximum of 30 servers for a merged system
- Preloaded with Ubuntu Linux 18.04 LTS & WAVE VMS client & server
SYSTEM
| Video Management Software | Wisenet WAVE |
| Pre-loaded Licenses | 4x Wisenet WAVE Professional licenses |
| Recording Bandwidth | Up to 150 Mbps |
| OS Drive Bays | 1 x eMMC SSD (embedded) |
| Data Drive Bays | 4 x 3.5" SATA HDDs |
| Data Storage | Up to 24TB raw |
| Indicator Lights | Power, Alarm, HDD, Network, Record, PoE Over Budget |
| Network Interface | 2 x RJ-45, Gigabit Ethernet, 16 x PoE+ 100Mbps |
| Alarm I/O | 4 x Alarm Input / 2x Alarm Output |
| PoE Camera Ports | 16 x 100Mbps, Each Maximum 30W 802.3at PoE+, Total Budget 200W |
| Mouse | Included |
| Rack Mount Brackets | Included |
| Mechanical | Form Factor | 2U rack mount chassis |
| Color / Material | Black / Metal | |
| Dimensions | 17.32" x 3.54" x 16.78" (440mm x 89.8mm x 426.3mm) | |
| Weight | 11.46lb (5.2kg) without hard drives | |
| Electrical | Power Supply | 320W maximum with 4 HDD, Maximum PoE; 63W 4 HDDs, PoE Off |
| Power Input | 100 ~ 240V AC | |
| Environmental | Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Operating Humidity | 20% to 85% RH, non-condensing | |
| Certification | UL, CE, FCC | |
Name
Description
Size
Downloads
File
Datasheet
0.3mb
