Hanwha - WRR-P-E200W-24TB - Wisenet WAVE optimized 1U rack server-24TB
Part number:
WRR-P-E200W-24TB
Price:
The WRR-P-E200W offers an affordable and reliable shallow depth 1U rackmount solution for any entry-level deployment. Up to 42TB of raw video-optimized storage is provided by 24/7 duty cycle SATA drives.
The latest Intel Xeon E-2124 Processor allows for high powered computing power, and 16GB of DDR4 RAM provides the system resources to scale as needed.
A dedicated solid-state drive for applications and the operating system enables fast boot and load times. The five-year, on-site, Next Business Day, Keep Your Hard Drive warranty ensures peace of mind.
Each server is pre-configured with Wisenet WAVE VMS and preloaded with 4 Professional licenses to ensure quick and easy deployment with minimum setup time.
Features:
- Preloaded and configured with Wisenet WAVE video management system
- Up to 42TB of Raw Storage
- 470 Mbps of recording throughput
- SSD & 24/7 Duty Cycle SATA Drives
- Shallow Depth Server
- Includes USB mouse and keyboard
- Includes Sliding Rack Rail with Cable Management Arm
- 5-Year, On-site, Next Business Day, Keep Your Hard Drive Warranty
- Supports Wisenet and ONVIF conformant IP cameras
- IPMI Management
- Powered by Microsoft Windows 10 Professional
| SYSTEM | |
| Video Management Software | Wisenet WAVE |
| Recording Bandwidth | Up to 470 Mbps |
| OS Drive Bays | 1 x 240GB M2.5 SSD (internally mounted) |
| OS / Data Drive Bays | 4 x 3.5" Hot Swappable Bays (1 minimum used for OS) |
| Data Storage | Up to 42TB raw storage |
| Pre-loaded Licenses | 4 x Wisenet WAVE Professional license |
| Network Interface | 2 x RJ45 Gigabit Ethernet |
| Processor | 1 x Intel®Xeon® E-2124 Series Processor, 3.30 to 4.30Ghz, 4 Cores/ 4 Threads |
| Memory | 16GB, 2 x 8GB DDR4 |
| Operating System | Windows 10 Professional / Windows Server 2016 Standard / Ubuntu 18.04 LTS |
| Video Outputs | 1 x VGA (For system configuration only. Not optimized for camera viewing) |
| USB Ports | 2 x USB 3.0 (Rear), 1 x USB 2.0 (Front), 1 x USB 3.0 (Internal) |
| Other Ports | Serial |
| Keyboard & Mouse | Included |
| Sliding Rail Kit | Included, with Cable Management Arm |
| MECHANICAL / ELECTRICAL / ENVIRONMENTAL |
| Form Factor | 1U shallow depth rack mount chassis |
| Color / Material | Black / Metal |
| Dimensions (WxDxH) | 19" (482.6mm) x 24.2" (614.68mm) x 1.67" (42.8mm) |
| Weight | Maximum 26.89 lb/12.2 Kg |
| Power Supply | 250W Bronze |
| Power Input | 100 ~ 240V AC |
| Power Consumption | Maximum 250W |
| Operating Temperature | Standard: 50°F ~ 95°F (10°C ~ 35°C) at 10% to 80% RH with 84.2°F maximum dew point. Refer to manual for operating temperature derating. Extended: 40°F ~ 104°F (5°C ~ 40°C) at 5% to 85% RH with 84.2°F dew point. |
| Storage Temperature | -40°F ~ 149°F (-40°C ~ 65°C ) |
| Operating Humidity | 10% to 80% RH with 84.2°F maximum dew point |
