1U Wisenet WAVE Network Video Recorder with 4 Professional licenses, Wisenet WAVE pre-installed, 12TB raw (7TB usable after disk formatting & JBOD configuration), 470 Mbps recording B/W, 4 HDD Bay (3.5" with up to 3 hot plug drives), Intel Xeon, 16GB RAM, 480GB SSD OS drive, Windows 10 IoT Enterprise, Nvidia GPU, MiniDP output, VGA output, Dual GbE NICs, IPMI, Single 250W power supply, Keyboard and mouse included, Rail kit included
Features:
- Up to 48TB of Raw Storage
- 470 Mbps of recording throughput
- SSD & 24/7 Duty Cycle SATA Drives
- Dedicated GPU for client application
- Shallow Depth Server
- Includes USB mouse and keyboard
- Includes Sliding Rack Rail with Cable Management Arm
- 5-Year, On-site, Next Business Day, Keep Your Hard Drive Warranty
- Supports Wisenet and ONVIF conformant IP cameras
- IPMI Management
- Powered by Microsoft Windows 10 IoT
System
|
Video Management Software |
Wisenet WAVE |
|
Recording Bandwidth |
Up to 470 Mbps |
|
OS Drive Bays |
1 x 480GB M2.5 SSD (internally mounted) |
|
OS / Data Drive Bays |
4 x 3.5" Hot Swappable Bays (1 minimum used for OS) |
|
Data Storage |
Up to 48TB raw storage |
|
Pre-loaded Licenses |
4 x Wisenet WAVE Professional license |
|
Network Interface |
2 x RJ45 Gigabit Ethernet |
|
Processor |
1 x Intel® Xeon® Processor |
|
Memory |
16GB, 2 x 8GB DDR4 |
|
Operating System |
Windows 10 IoT / Windows Server 2019 Standard / Ubuntu 18.04 LTS |
|
Video Outputs |
NVIDIA Quadro P400 3x MiniDisplay Port (1x HDMI adapter), 1 x VGA |
|
USB Ports |
2 x USB 3.0 (Rear), 1 x USB 2.0 (Front), 1 x USB 3.0 (Internal) |
|
Other Ports |
Serial |
|
Keyboard & Mouse |
Included |
|
Sliding Rail Kit |
Included, with Cable Management Arm |
|
Mechanical |
Form Factor |
1U shallow depth rack mount chassis |
|
Color / Material |
Black / Metal |
|
|
Dimensions (WxDxH) |
19" (482.6mm) x 24.2" (614.68mm) x 1.67" (42.8mm) |
|
|
Weight |
Maximum 26.89 lb/12.2 Kg |
|
|
Electrical |
Power Supply |
250W Bronze |
|
Power Input |
100 ~ 240V AC |
|
|
Power Consumption |
Maximum 250W |
|
|
Environmental |
Operating Temperature |
Standard: 50°F ~ 95°F (10°C ~ 35°C) at 10% to 80% RH with 84.2°F maximum dew point. Refer to manual for operating temperature derating. Extended: 40°F ~ 104°F (5°C ~ 40°C) at 5% to 85% RH with 84.2°F dew point. |
|
Storage Temperature |
-40°F ~ 149°F (-40°C ~ 65°C ) |
|
|
Operating Humidity |
10% to 80% RH with 84.2°F maximum dew point. |
|
|
Certiÿcation |
UL, cUL, CB, FCC, 80 Plus Platinum |
|
