Mini-tower form factor Wisenet WAVE Network Video Recorder with 4 Professional licenses, Wisenet WAVE pre-installed, 12TB raw, 170 Mbps recording B/W, (1) 3.5" HDD, (10th Gen) Intel Core i3, 8GB RAM, 256 GB SSD OS Drive, Ubuntu Linux 18.04 LTS, (2) DisplayPort output, (1) DisplayPort to HDMI adapter included, Dual GbE NICs, Single 550W power supply, Keyboard and mouse included
Features:
- Preloaded and configured with Wisenet WAVE video management system
- Includes (4) four Wisenet WAVE Professional licenses
- 170 Mbps of recording throughput
- Up to 16TB internal storage
- Supports Wisenet and ONVIF conformant IP cameras
- Dual DisplayPort monitor outputs
- Dual GbE NICs
- Includes USB mouse and keyboard
- 5-Year, On-site, Next Business Day, Keep Your Hard Drive Warranty
- Powered by the Ubuntu 18.04 Linux Operating System
|
Video Management Software |
Wisenet WAVE |
|
Pre-loaded Licenses |
4 x Wisenet WAVE Professional license |
|
Recording Bandwidth |
Up to 170 Mbps |
|
Processor |
1 x Intel® Core® i3 10th Generation |
|
Memory |
8GB DDR4 |
|
Operating System |
Windows 10 IoT Enterprise LTSC / Ubuntu Linux 18.04 LTS |
|
Video Outputs |
2 x DisplayPort w/ 1 x DisplayPort to HDMI adapter |
|
USB Ports |
Rear (4) USB 3.0, (2) USB 2.0; Front (1) USB 3.0, (2) USB 2.0, (1) USB 3.0 Type-C |
|
Other Ports |
3.5mm audio output, PS2 Keyboard & Mouse, Seria |
|
Keyboard & Mouse |
Included |
|
Data Drive Bays |
3x 3.5" SATA HDDs |
|
Data Storage |
Up to 16TB raw storage |
|
Network Interface |
2 x RJ-45, Gigabit Ethernet |
|
Keyboard & Mouse |
Included |
|
Mechanical |
Form Factor |
Small Form Factor Workstation |
|
Color / Material |
Black / Metal & Plastic |
|
|
Dimensions (WxDxH) |
3.7" x 11.5" x 11.4" (97mm x 292mm x 290mm) |
|
|
Weight |
11.57 lbs (5.26 kg) |
|
|
Electrical |
Power Supply |
1x 200W 80 Plus Bronze |
|
Power Input |
100 ~ 240V AC |
|
|
Power Consumption |
Maximum 200W |
|
|
Environmental |
Operating Temperature |
41°F ~ 95°F (5°C ~ 35°C) |
|
Storage Temperature |
-40°F ~ 149°F (-40°C ~ 65°C ) |
|
|
Operating Humidity |
20% to 80% relative humidity (non-condensing) |
|
|
Certification |
UL, cUL, CB, FCC, 80 Plus Bronze |
|
