Micro form factor Wisenet WAVE Network Video Recorder with 4 Professional licenses, Wisenet WAVE pre-installed, 12TB raw, 45 Mbps recording B/W, (1) 2.5" HDD, (10th Gen) Intel Core i3, 8GB RAM, 256 GB SSD OS Drive, Windows 10 IoT Enterprise, (1) HDMI, (1) DisplayPort output, , 1 GbE NIC, , Keyboard and mouse included
Features:
- Micro form factor Wisenet WAVE Network Video Recorder
- Includes 4 Professional licenses
- Wisenet WAVE pre-installed
- 45 Mbps recording B/W
- (1) 2.5" HDD
- (10th Gen) Intel Core i3, 8GB RAM
- 256 GB SSD OS Drive
- Windows 10 IoT Enterprise
- (1) HDMI, (1) DisplayPort output
- 1 GbE NIC
- Keyboard and mouse included
System
|
Video Management Software |
Wisenet WAVE |
|
Recording Bandwidth |
Up to 45Mbps |
|
Pre-loaded licenses |
4 x Wisenet WAVE Professional License |
|
OS Drive Bay |
1 x 256GB M2.5 SSD OS Drive |
|
Data Drive Storage |
1x 2TB SATA for Video Storage |
|
Network Interface |
1 x 1GbE RJ45 Ports |
|
Processor |
1 x Intel® Core™ i3-10100T 3.0Ghz to 3.8Ghz (4 Cores, 8 Threads, 6MB) |
|
Memory |
8GB DDR4 |
|
Operating System |
Windows 10 IoT Enterprise LTSC. |
|
Video Outputs |
DisplayPort, HDMI |
|
USB Ports |
Rear: (2) USB 3.1 Gen 1, (2) USB 2.0; Front: (2) USB 3.1 Gen 1 |
|
Other Ports |
2x 3.5mm audio headset output/input |
|
Keyboard & Mouse |
Included |
|
Mechanical |
Form Factor |
Micro form factor server |
|
Color / Material |
Black / Metal & Plastic |
|
|
Dimensions (WxDxH) |
1.4” x 7.0” x 7.2” (36mm x 178mm x 182mm) |
|
|
Weight |
3.04 lbs (1.38 kg) |
|
|
Electrical |
Power Input |
100 ~ 240V AC |
|
Power Consumption |
65W |
|
|
Environmental |
Operating Temperature |
41°F ~ 95°F (5°C ~ 35°C) |
|
Storage Temperature |
-40°F ~ 149°F (-40°C ~ 65°C ) |
|
|
Operating Humidity |
20% to 80% relative humidity (non-condensing) |
|
|
Certification |
UL, cUL, CB, FCC, |
|
