Hanwha - WRT-P-3103MW-2TB - Micro Form Factor WAVE Recording Server
Part number:
WRT-P-3103MW-2TB
Price:
The WRT-P-3103MW server is a micro form factor, easy-to-deploy recording solution. The server has a 256GB solid-state drive for the Windows 10 operating system to provide fast boot and load times. This micro server offers unrivaled deployment flexibility, allowing for its small chassis to be deployed in any small business environment. An optional VESA mount allows the server to be inconspicuously mounted behind a monitor.
Features:
- Micro form factor Wisenet WAVE Network Video Recorder
- Includes 4 Professional licenses
- Wisenet WAVE pre-installed
- 45 Mbps recording B/W
- (1) 2.5" HDD
- (13th Gen) Intel Core i3, 8GB RAM
- 256 GB SSD OS Drive
- Windows 10 IoT Enterprise
- (1) HDMI, (1) DisplayPort, (1) VGA
- 1 GbE NIC
- Keyboard and mouse included
| SYSTEM | |
| Video Management Software | Wisenet WAVE |
| Recording Bandwidth | Up to 45Mbps |
| Pre-loaded licenses | 4 x Wisenet WAVE Professional License |
| OS Drive Bay | 1 x 256GB M2.5 SSD OS Drive |
| Data Drive Storage | 1x 2TB SATA for Video Storage |
| Network Interface | 1 x 1GbE RJ45 Ports |
| Processor | 1 x Intel® Core™ i3 13th Generation |
| Memory | 8GB DDR4 |
| Operating System | Windows 10 IoT Enterprise |
| Video Outputs | 1x HDMI, 1x DP, 1x VGA, 1x DP to HDMI adapter included |
| USB Ports | Rear: (2) USB 3.2 Gen 1, (2) USB 2.0; Front: (2) USB 3.2 Gen 1 |
| Other Ports | 2x 3.5mm audio headset output/input |
| Keyboard & Mouse | Included |
| MECHANICAL / ELECTRICAL / ENVIRONMENTAL | ||
| Mechanical | Form Factor | Micro form factor server |
| Color / Material | Black / Metal & Plastic | |
Dimensions (WxDxH) | 1.4” x 7.0” x 7.2” (36mm x 178mm x 182mm) | |
| Weight | 2.95 lbs (1.34 kg) | |
| Electrical | Power Input | 100 ~ 240V AC |
| Power Consumption | 65W | |
Environmental | Operating Temperature | 50°F to 95°F (10°C to 35°C) |
Storage Temperature | -40°F ~ 149°F (-40°C ~ 65°C ) | |
| Operating Humidity | 20% to 80% relative humidity (non-condensing) | |
| Certification | UL, cUL, CB, FCC, | |
