Hanwha - WRT-P-3104W-4TB - Mini-tower form factor Wisenet WAVE Network Video Recorder with 4 Professional licenses, 4TB
Part number:
WRT-P-3104W-4TB
Price:
The WRT-P-3104W series dual purpose Wisenet WAVE server and client is built into a compact mini-tower form running Windows 11 IoT Enterprise 2024 or Ubuntu Linux 22.04 LTS. This ready to deploy solution can manage up to 170 Mbps of recording throughput and up to 16TB of storage for a single site or as an addition to your existing Wisenet WAVE system.
Each comes with Wisenet WAVE VMS and 4 Professional licenses to ensure quick and easy deployment with minimum setup time.
Features:
- Preloaded and configured with Wisenet WAVE video management system & tools
- Up to 16TB of Raw Storage
- 170 Mbps of recording throughput
- Includes (4) four Wisenet WAVE Professional licenses
- Includes USB mouse and keyboard
- 5-Year, On-site, Next Business Day, Keep Your Hard Drive Warranty
- Supports Wisenet and ONVIF conformant IP cameras
| SYSTEM | |
| Video Management Software | Wisenet WAVE up to 64 channels |
| Included Licenses | 4 x Wisenet WAVE Professional license |
| Recording Bandwidth | Up to 170 Mbps |
| OS Drive Bays | 1 x 256GB M.2 SSD (internally mounted) |
| Data Drive Bays | 3x 3.5" SATA HDDs |
| Data Storage | Up to 16TB raw storage |
| Network Interface | (2) 1GbE RJ45 Ports (1 on-board & 1 PCIe NIC) |
| Processor | 1 x Intel® Core® i3 14th Generation |
| Memory | 16GB DDR4 |
| Operating System | Windows 11 IoT Enterprise 2024 / Ubuntu Linux 22.04 LTS |
| Video Outputs | 2 x DP w/ 1 x DP to HDMI adapter |
| USB Ports | Rear 2x USB 3.2 Gen 2, 2x USB 3.2 Gen 2 Type-C, 2x USB 2.0; Front: 2x USB 3.2 Gen 1, 1x USB 3.2 Gen 2 Type-C, 1x USB 3.2 Gen 2x2 Type-C |
| Other Ports | Front: 1x 3.5mm Universal Audio, Back: 1x 3.5mm audio output |
| Keyboard & Mouse | Included |
| MECHANICAL / ELECTRICAL / ENVIRONMENTAL | |
| Mechanical | Form Factor | Tower |
| Color / Material | Black / Metal | |
| Dimensions (HxWxD) | 14.68" x 6.81" x 16.54" (372.9mm x 173mm x 420mm) | |
| Weight | 24 lbs (10.68 kg) | |
| Electrical | Power Supply | 500W 80 Plus Platinum |
| Power Input | 100 ~ 240V AC | |
| Power Consumption | Maximum 500W | |
| Environmental | Operating Temperature | 50°F to 95°F (10°C to 35°C) |
| Storage Temperature | -40°F to 149°F (-40°C to 65°C) | |
| Operating Humidity | 20% to 85% (non-condensing) | |
| Certification | UL, cUL, CB, FCC, 80 Plus Gold | |
