Mini-tower form factor Wisenet WAVE Network Video Recorder with 4 Professional licenses, Wisenet WAVE pre-installed, 16TB raw, 470 Mbps recording B/W, (1) 3.5" HDD, (10th Gen) Intel Core i5, 16GB RAM, 256 GB SSD OS Drive, Windows 10 IoT Enterprise, (2) DisplayPort output, (1) DisplayPort to HDMI adapter included, Dual GbE NICs, Single 550W power supply, Keyboard and mouse included
Features:
- Preloaded and configured with Wisenet WAVE video management system
- Includes (4) four Wisenet WAVE Professional licenses
- 470 Mbps of recording throughput
- Up to 36TB internal storage
- Supports Wisenet and ONVIF conformant IP cameras
- Dual DisplayPort monitor outputs
- Dual GbE NICs
- Includes USB mouse and keyboard
- 5-Year, On-site, Next Business Day, Keep Your Hard Drive Warranty
- Powered by the Microsoft Windows 10 IoT Enterprise LTSC Operating System
System
|
Video Management Software |
Wisenet WAVE |
|
Recording Bandwidth |
Up to 470 Mbps |
|
Pre-loaded Licenses |
4 x Wisenet WAVE Professional license |
|
OS Drive Bays |
1 x 256GB SSD (internally mounted) |
|
Data Drive Bays |
3x 3.5" SATA HDDs |
|
Data Storage |
Up to 36TB raw storage |
|
Network Interface |
2 x RJ-45, Gigabit Ethernet |
|
Processor |
1 x Intel® Core® i5 10th Generation |
|
Memory |
16GB DDR4 |
|
Operating System |
Windows 10 IoT Enterprise LTSC / Ubuntu Linux 18.04 LTS |
|
Video Outputs |
2x DisplayPort with 1 x DisplayPort to HDMI adapter |
|
USB Ports |
Rear (4) USB 3.0, (2) USB 2.0; Front (1) USB 3.0, (2) USB 2.0, (1) USB 3.0 Type-C |
|
Other Ports |
3.5mm audio output, PS2 Keyboard & Mouse, Serial |
|
Keyboard & Mouse |
Included |
|
Mechanical |
Form Factor |
Tower |
|
Color / Material |
Black / Metal |
|
|
Dimensions (HxWxD) |
13.19” x 6.95” x 13.58” (33.5cm x 17.7cm x 34.5cm) |
|
|
Weight |
24 lbs (10.8 kg) |
|
|
Electrical |
Power Supply |
460W 80 Plus Gold |
|
Power Input |
100 ~ 240V AC |
|
|
Power Consumption |
Maximum 550W |
|
|
Environmental |
Operating Temperature |
32°F ~ 95°F (0°C ~ 35°C ) |
|
Storage Temperature |
-40°F ~ 149°F (-40°C ~ 65°C) |
|
|
Operating Humidity |
10% to 80% RH non-condensing |
|
|
Certification |
UL, cUL, CB, FCC, 80 Plus Gold |
|
