Hanwha - WWT-P-3203W - Wisenet WAVE Client Workstation
Part number:
WWT-P-3203W
Price:
The WWT-P-3203 series client workstation is an easily deployable solution that can be used on-site or remotely to access your Wisenet WAVE video recorder, running Windows 10 IoT Enterprise.
Features:
- Preloaded and configured with Wisenet WAVE video management system
- Supports Wisenet and ONVIF conformant IP cameras
- Latest Intel 13th generation Core i3 CPU
- Nvidia Quadro T400 w/ (3) mDP Output
- 2x mDP to HDMI adapters included
- Includes USB mouse and keyboard
- 5-Year, On-site, Next Business Day, Keep Your Hard Drive Warranty
- Powered by Microsoft Windows 10 IoT Enterprise
| SYSTEM | |
| Video Management Software | Wisenet WAVE |
| OS Drive Bays | 1 x 256GB SSD (internally mounted) |
| Network Interface | 1 x 1GbE RJ-45 Ports |
| Processor | 1 x Intel® Core™ i3 13th Generation |
| Memory | 8GB DDR4 |
| Operating System | Windows 10 IoT Enterprise / Ubuntu 20.04 LTS |
| Video Outputs | Nvidia Quadro T400 GPU 3x mDP with 2x HDMI adapters |
| USB Ports | Rear: (2) USB 3.2 Gen 1, (2) USB 2.0; Front: (2) USB 3.2 Gen 1, (2) USB 2.0 |
| Other Ports | 3.5mm audio output |
| Keyboard & Mouse | Included |
| MECHANICAL / ELECTRICAL / ENVIRONMENTAL | ||
| Mechanical | Form Factor | Small Form Factor Workstation |
| Color / Material | Black / Metal & Plastic | |
Dimensions (WxDxH) | 3..65" x 11.53" x 11.42" (92.6mm x 292.8mm x 290mm) | |
| Weight | 11.38 lbs (5.16 kg) | |
| Electrical | Power Supply | 1x 180W 80 Plus Bronze |
| Power Input | 100 ~ 240V AC | |
| Power Consumption | Maximum 180W | |
Environmental | Operating Temperature | 41°F ~ 113°F (5°C ~ 45°C) |
Storage Temperature | -40°F ~ 158°F (-40°C ~ 70°C ) | |
| Operating Humidity | 20% to 80% relative humidity (non-condensing) | |
| Certification | UL, cUL, CB, FCC, 80 Plus Bronze | |
Name
Description
Size
Downloads
File
Specification
0.5mb
File
Quick Guide
1.6mb
File
Hanwha Techwin America - NDAA Compliant Product List
0.4mb
